chemical = Paragraph("H₂O", styles['Normal'])

# Superscripts: use tag
squared = Paragraph("x2 + y2", styles['Normal'])
```

For canvas-drawn text (not Paragraph objects), manually adjust font the size and position rather than using Unicode subscripts/superscripts.

## Command-Line Tools

### pdftotext (poppler-utils)
```bash
# Extract text
pdftotext input.pdf output.txt

# Extract text preserving layout
pdftotext -layout input.pdf output.txt

# Extract specific pages
pdftotext -f 1 -l 5 input.pdf output.txt # Pages 1-5
```

### qpdf
```bash
# Merge PDFs
qpdf --empty --pages file1.pdf file2.pdf -- merged.pdf

# Split pages
qpdf input.pdf --pages . 1-5 -- pages1-5.pdf
qpdf input.pdf --pages . 6-10 -- pages6-10.pdf

# Rotate pages
qpdf input.pdf output.pdf --rotate=+90:1 # Rotate page 1 by 90 degrees

# Remove password
qpdf --password=mypassword --decrypt encrypted.pdf decrypted.pdf
```

### pdftk (if available)
```bash
# Merge
pdftk file1.pdf file2.pdf cat output merged.pdf

# Split
pdftk input.pdf burst

# Rotate
pdftk input.pdf rotate 1east output rotated.pdf
```

## Common Tasks

### Extract Text from Scanned PDFs
```python
# Requires: pip install pytesseract pdf2image
import pytesseract
from pdf2image import convert_from_path

# Convert PDF to images
images = convert_from_path('scanned.pdf')

# OCR each page
text = ""
for i, image in enumerate(images):
text += f"Page {i+1}:\n"
text += pytesseract.image_to_string(image)
text += "\n\n"

print(text)
```

### Add Watermark
```python
from pypdf import PdfReader, PdfWriter

# Create watermark (or load existing)
watermark = PdfReader("watermark.pdf").pages[0]

# Apply to all pages
reader = PdfReader("document.pdf")
writer = PdfWriter()

for page in reader.pages:
page.merge_page(watermark)
writer.add_page(page)

with open("watermarked.pdf", "wb") as output:
writer.write(output)
```

### Extract Images
```bash
# Using pdfimages (poppler-utils)
pdfimages -j input.pdf output_prefix

# This extracts all images as output_prefix-000.jpg, output_prefix-001.jpg, etc.
```

### Password Protection
```python
from pypdf import PdfReader, PdfWriter

reader = PdfReader("input.pdf")
writer = PdfWriter()

for page in reader.pages:
writer.add_page(page)

# Add password
writer.encrypt("userpassword", "ownerpassword")

with open("encrypted.pdf", "wb") as output:
writer.write(output)
```

## Quick Reference

| Task | Best Tool | Command/Code |
|------|-----------|--------------|
| Merge PDFs | pypdf | `writer.add_page(page)` |
| Split PDFs | pypdf | One page per file |
| Extract text | pdfplumber | `page.extract_text()` |
| Extract tables | pdfplumber | `page.extract_tables()` |
| Create PDFs | reportlab | Canvas or Platypus |
| Command line merge | qpdf | `qpdf --empty --pages ...` |
| OCR scanned PDFs | pytesseract | Convert to image first |
| Fill PDF forms | pdf-lib or pypdf (see FORMS.md) | See FORMS.md |

## Next Steps

- For advanced pypdfium2 usage, see REFERENCE.md
- For JavaScript libraries (pdf-lib), see REFERENCE.md
- If you need to fill out a PDF form, follow the instructions in FORMS.md
- For troubleshooting guides, see REFERENCE.md

## Resource Files

### LICENSE.txt

[Download LICENSE.txt](/skills/pdf/LICENSE.txt)

_Binary resource_

### forms.md

[Download forms.md](/skills/pdf/forms.md)

_Binary resource_

### reference.md

[Download reference.md](/skills/pdf/reference.md)

_Binary resource_

### scripts/check_bounding_boxes.py

[Download scripts/check_bounding_boxes.py](/skills/pdf/scripts/check_bounding_boxes.py)

```python
from dataclasses import dataclass
import json
import sys

@dataclass
class RectAndField:
rect: list[float]
rect_type: str
field: dict

def get_bounding_box_messages(fields_json_stream) -> list[str]:
messages = []
fields = json.load(fields_json_stream)
messages.append(f"Read {len(fields['form_fields'])} fields")

def rects_intersect(r1, r2):
disjoint_horizontal = r1[0] >= r2[2] or r1[2] <= r2[0]
disjoint_vertical = r1[1] >= r2[3] or r1[3] <= r2[1]
return not (disjoint_horizontal or disjoint_vertical)

rects_and_fields = []
for f in fields["form_fields"]:
rects_and_fields.append(RectAndField(f["label_bounding_box"], "label", f))
rects_and_fields.append(RectAndField(f["entry_bounding_box"], "entry", f))

has_error = False
for i, ri in enumerate(rects_and_fields):
for j in range(i + 1, len(rects_and_fields)):
rj = rects_and_fields[j]
if ri.field["page_number"] == rj.field["page_number"] and rects_intersect(ri.rect, rj.rect):
has_error = True
if ri.field is rj.field:
messages.append(f"FAILURE: intersection between label and entry bounding boxes for `{ri.field['description']}` ({ri.rect}, {rj.rect})")
else:
messages.append(f"FAILURE: intersection between {ri.rect_type} bounding box for `{ri.field['description']}` ({ri.rect}) and {rj.rect_type} bounding box for `{rj.field['description']}` ({rj.rect})")
if len(messages) >= 20:
messages.append("Aborting further checks; fix bounding boxes and try again")
return messages
if ri.rect_type == "entry":
if "entry_text" in ri.field:
font_size = ri.field["entry_text"].get("font_size", 14)
entry_height = ri.rect[3] - ri.rect[1]
if entry_height < font_size:
has_error = True
messages.append(f"FAILURE: entry bounding box height ({entry_height}) for `{ri.field['description']}` is too short for the text content (font size: {font_size}). Increase the box height or decrease the font size.")
if len(messages) >= 20:
messages.append("Aborting further checks; fix bounding boxes and try again")
return messages

if not has_error:
messages.append("SUCCESS: All bounding boxes are valid")
return messages

if __name__ == "__main__":
if len(sys.argv) != 2:
print("Usage: check_bounding_boxes.py [fields.json]")
sys.exit(1)
with open(sys.argv[1]) as f:
messages = get_bounding_box_messages(f)
for msg in messages:
print(msg)
```

### scripts/check_fillable_fields.py

[Download scripts/check_fillable_fields.py](/skills/pdf/scripts/check_fillable_fields.py)

```python
import sys
from pypdf import PdfReader

reader = PdfReader(sys.argv[1])
if (reader.get_fields()):
print("This PDF has fillable form fields")
else:
print("This PDF does not have fillable form fields; you will need to visually determine where to enter data")
```

### scripts/convert_pdf_to_images.py

[Download scripts/convert_pdf_to_images.py](/skills/pdf/scripts/convert_pdf_to_images.py)

```python
import os
import sys

from pdf2image import convert_from_path

def convert(pdf_path, output_dir, max_dim=1000):
images = convert_from_path(pdf_path, dpi=200)

for i, image in enumerate(images):
width, height = image.size
if width > max_dim or height > max_dim:
scale_factor = min(max_dim / width, max_dim / height)
new_width = int(width * scale_factor)
new_height = int(height * scale_factor)
image = image.resize((new_width, new_height))

image_path = os.path.join(output_dir, f"page_{i+1}.png")
image.save(image_path)
print(f"Saved page {i+1} as {image_path} (size: {image.size})")

print(f"Converted {len(images)} pages to PNG images")

if __name__ == "__main__":
if len(sys.argv) != 3:
print("Usage: convert_pdf_to_images.py [input pdf] [output directory]")
sys.exit(1)
pdf_path = sys.argv[1]
output_directory = sys.argv[2]
convert(pdf_path, output_directory)
```

### scripts/create_validation_image.py

[Download scripts/create_validation_image.py](/skills/pdf/scripts/create_validation_image.py)

```python
import json
import sys

from PIL import Image, ImageDraw

def create_validation_image(page_number, fields_json_path, input_path, output_path):
with open(fields_json_path, 'r') as f:
data = json.load(f)

img = Image.open(input_path)
draw = ImageDraw.Draw(img)
num_boxes = 0

for field in data["form_fields"]:
if field["page_number"] == page_number:
entry_box = field['entry_bounding_box']
label_box = field['label_bounding_box']
draw.rectangle(entry_box, outline='red', width=2)
draw.rectangle(label_box, outline='blue', width=2)
num_boxes += 2

img.save(output_path)
print(f"Created validation image at {output_path} with {num_boxes} bounding boxes")

if __name__ == "__main__":
if len(sys.argv) != 5:
print("Usage: create_validation_image.py [page number] [fields.json file] [input image path] [output image path]")
sys.exit(1)
page_number = int(sys.argv[1])
fields_json_path = sys.argv[2]
input_image_path = sys.argv[3]
output_image_path = sys.argv[4]
create_validation_image(page_number, fields_json_path, input_image_path, output_image_path)
```

### scripts/extract_form_field_info.py

[Download scripts/extract_form_field_info.py](/skills/pdf/scripts/extract_form_field_info.py)

```python
import json
import sys

from pypdf import PdfReader

def get_full_annotation_field_id(annotation):
components = []
while annotation:
field_name = annotation.get('/T')
if field_name:
components.append(field_name)
annotation = annotation.get('/Parent')
return ".".join(reversed(components)) if components else None

def make_field_dict(field, field_id):
field_dict = {"field_id": field_id}
ft = field.get('/FT')
if ft == "/Tx":
field_dict["type"] = "text"
elif ft == "/Btn":
field_dict["type"] = "checkbox"
states = field.get("/_States_", [])
if len(states) == 2:
if "/Off" in states:
field_dict["checked_value"] = states[0] if states[0] != "/Off" else states[1]
field_dict["unchecked_value"] = "/Off"
else:
print(f"Unexpected state values for checkbox `${field_id}`. Its checked and unchecked values may not be correct; if you're trying to check it, visually verify the results.")
field_dict["checked_value"] = states[0]
field_dict["unchecked_value"] = states[1]
elif ft == "/Ch":
field_dict["type"] = "choice"
states = field.get("/_States_", [])
field_dict["choice_options"] = [{
"value": state[0],
"text": state[1],
} for state in states]
else:
field_dict["type"] = f"unknown ({ft})"
return field_dict

def get_field_info(reader: PdfReader):
fields = reader.get_fields()

field_info_by_id = {}
possible_radio_names = set()

for field_id, field in fields.items():
if field.get("/Kids"):
if field.get("/FT") == "/Btn":
possible_radio_names.add(field_id)
continue
field_info_by_id[field_id] = make_field_dict(field, field_id)

radio_fields_by_id = {}

for page_index, page in enumerate(reader.pages):
annotations = page.get('/Annots', [])
for ann in annotations:
field_id = get_full_annotation_field_id(ann)
if field_id in field_info_by_id:
field_info_by_id[field_id]["page"] = page_index + 1
field_info_by_id[field_id]["rect"] = ann.get('/Rect')
elif field_id in possible_radio_names:
try:
on_values = [v for v in ann["/AP"]["/N"] if v != "/Off"]
except KeyError:
continue
if len(on_values) == 1:
rect = ann.get("/Rect")
if field_id not in radio_fields_by_id:
radio_fields_by_id[field_id] = {
"field_id": field_id,
"type": "radio_group",
"page": page_index + 1,
"radio_options": [],
}
radio_fields_by_id[field_id]["radio_options"].append({
"value": on_values[0],
"rect": rect,
})

fields_with_location = []
for field_info in field_info_by_id.values():
if "page" in field_info:
fields_with_location.append(field_info)
else:
print(f"Unable to determine location for field id: {field_info.get('field_id')}, ignoring")

def sort_key(f):
if "radio_options" in f:
rect = f["radio_options"][0]["rect"] or [0, 0, 0, 0]
else:
rect = f.get("rect") or [0, 0, 0, 0]
adjusted_position = [-rect[1], rect[0]]
return [f.get("page"), adjusted_position]

sorted_fields = fields_with_location + list(radio_fields_by_id.values())
sorted_fields.sort(key=sort_key)

return sorted_fields

def write_field_info(pdf_path: str, json_output_path: str):
reader = PdfReader(pdf_path)
field_info = get_field_info(reader)
with open(json_output_path, "w") as f:
json.dump(field_info, f, indent=2)
print(f"Wrote {len(field_info)} fields to {json_output_path}")

if __name__ == "__main__":
if len(sys.argv) != 3:
print("Usage: extract_form_field_info.py [input pdf] [output json]")
sys.exit(1)
write_field_info(sys.argv[1], sys.argv[2])
```

### scripts/extract_form_structure.py

[Download scripts/extract_form_structure.py](/skills/pdf/scripts/extract_form_structure.py)

```python
"""
Extract form structure from a non-fillable PDF.

This script analyzes the PDF to find:
- Text labels with their exact coordinates
- Horizontal lines (row boundaries)
- Checkboxes (small rectangles)

Output: A JSON file with the form structure that can be used to generate
accurate field coordinates for filling.

Usage: python extract_form_structure.py
"""

import json
import sys
import pdfplumber

def extract_form_structure(pdf_path):
structure = {
"pages": [],
"labels": [],
"lines": [],
"checkboxes": [],
"row_boundaries": []
}

with pdfplumber.open(pdf_path) as pdf:
for page_num, page in enumerate(pdf.pages, 1):
structure["pages"].append({
"page_number": page_num,
"width": float(page.width),
"height": float(page.height)
})

words = page.extract_words()
for word in words:
structure["labels"].append({
"page": page_num,
"text": word["text"],
"x0": round(float(word["x0"]), 1),
"top": round(float(word["top"]), 1),
"x1": round(float(word["x1"]), 1),
"bottom": round(float(word["bottom"]), 1)
})

for line in page.lines:
if abs(float(line["x1"]) - float(line["x0"])) > page.width * 0.5:
structure["lines"].append({
"page": page_num,
"y": round(float(line["top"]), 1),
"x0": round(float(line["x0"]), 1),
"x1": round(float(line["x1"]), 1)
})

for rect in page.rects:
width = float(rect["x1"]) - float(rect["x0"])
height = float(rect["bottom"]) - float(rect["top"])
if 5 <= width <= 15 and 5 <= height <= 15 and abs(width - height) < 2:
structure["checkboxes"].append({
"page": page_num,
"x0": round(float(rect["x0"]), 1),
"top": round(float(rect["top"]), 1),
"x1": round(float(rect["x1"]), 1),
"bottom": round(float(rect["bottom"]), 1),
"center_x": round((float(rect["x0"]) + float(rect["x1"])) / 2, 1),
"center_y": round((float(rect["top"]) + float(rect["bottom"])) / 2, 1)
})

lines_by_page = {}
for line in structure["lines"]:
page = line["page"]
if page not in lines_by_page:
lines_by_page[page] = []
lines_by_page[page].append(line["y"])

for page, y_coords in lines_by_page.items():
y_coords = sorted(set(y_coords))
for i in range(len(y_coords) - 1):
structure["row_boundaries"].append({
"page": page,
"row_top": y_coords[i],
"row_bottom": y_coords[i + 1],
"row_height": round(y_coords[i + 1] - y_coords[i], 1)
})

return structure

def main():
if len(sys.argv) != 3:
print("Usage: extract_form_structure.py ")
sys.exit(1)

pdf_path = sys.argv[1]
output_path = sys.argv[2]

print(f"Extracting structure from {pdf_path}...")
structure = extract_form_structure(pdf_path)

with open(output_path, "w") as f:
json.dump(structure, f, indent=2)

print(f"Found:")
print(f" - {len(structure['pages'])} pages")
print(f" - {len(structure['labels'])} text labels")
print(f" - {len(structure['lines'])} horizontal lines")
print(f" - {len(structure['checkboxes'])} checkboxes")
print(f" - {len(structure['row_boundaries'])} row boundaries")
print(f"Saved to {output_path}")

if __name__ == "__main__":
main()
```

### scripts/fill_fillable_fields.py

[Download scripts/fill_fillable_fields.py](/skills/pdf/scripts/fill_fillable_fields.py)

```python
import json
import sys

from pypdf import PdfReader, PdfWriter

from extract_form_field_info import get_field_info

def fill_pdf_fields(input_pdf_path: str, fields_json_path: str, output_pdf_path: str):
with open(fields_json_path) as f:
fields = json.load(f)
fields_by_page = {}
for field in fields:
if "value" in field:
field_id = field["field_id"]
page = field["page"]
if page not in fields_by_page:
fields_by_page[page] = {}
fields_by_page[page][field_id] = field["value"]

reader = PdfReader(input_pdf_path)

has_error = False
field_info = get_field_info(reader)
fields_by_ids = {f["field_id"]: f for f in field_info}
for field in fields:
existing_field = fields_by_ids.get(field["field_id"])
if not existing_field:
has_error = True
print(f"ERROR: `{field['field_id']}` is not a valid field ID")
elif field["page"] != existing_field["page"]:
has_error = True
print(f"ERROR: Incorrect page number for `{field['field_id']}` (got {field['page']}, expected {existing_field['page']})")
else:
if "value" in field:
err = validation_error_for_field_value(existing_field, field["value"])
if err:
print(err)
has_error = True
if has_error:
sys.exit(1)

writer = PdfWriter(clone_from=reader)
for page, field_values in fields_by_page.items():
writer.update_page_form_field_values(writer.pages[page - 1], field_values, auto_regenerate=False)

writer.set_need_appearances_writer(True)

with open(output_pdf_path, "wb") as f:
writer.write(f)

def validation_error_for_field_value(field_info, field_value):
field_type = field_info["type"]
field_id = field_info["field_id"]
if field_type == "checkbox":
checked_val = field_info["checked_value"]
unchecked_val = field_info["unchecked_value"]
if field_value != checked_val and field_value != unchecked_val:
return f'ERROR: Invalid value "{field_value}" for checkbox field "{field_id}". The checked value is "{checked_val}" and the unchecked value is "{unchecked_val}"'
elif field_type == "radio_group":
option_values = [opt["value"] for opt in field_info["radio_options"]]
if field_value not in option_values:
return f'ERROR: Invalid value "{field_value}" for radio group field "{field_id}". Valid values are: {option_values}'
elif field_type == "choice":
choice_values = [opt["value"] for opt in field_info["choice_options"]]
if field_value not in choice_values:
return f'ERROR: Invalid value "{field_value}" for choice field "{field_id}". Valid values are: {choice_values}'
return None

def monkeypatch_pydpf_method():
from pypdf.generic import DictionaryObject
from pypdf.constants import FieldDictionaryAttributes

original_get_inherited = DictionaryObject.get_inherited

def patched_get_inherited(self, key: str, default = None):
result = original_get_inherited(self, key, default)
if key == FieldDictionaryAttributes.Opt:
if isinstance(result, list) and all(isinstance(v, list) and len(v) == 2 for v in result):
result = [r[0] for r in result]
return result

DictionaryObject.get_inherited = patched_get_inherited

if __name__ == "__main__":
if len(sys.argv) != 4:
print("Usage: fill_fillable_fields.py [input pdf] [field_values.json] [output pdf]")
sys.exit(1)
monkeypatch_pydpf_method()
input_pdf = sys.argv[1]
fields_json = sys.argv[2]
output_pdf = sys.argv[3]
fill_pdf_fields(input_pdf, fields_json, output_pdf)
```

### scripts/fill_pdf_form_with_annotations.py

[Download scripts/fill_pdf_form_with_annotations.py](/skills/pdf/scripts/fill_pdf_form_with_annotations.py)

```python
import json
import sys

from pypdf import PdfReader, PdfWriter
from pypdf.annotations import FreeText

def transform_from_image_coords(bbox, image_width, image_height, pdf_width, pdf_height):
x_scale = pdf_width / image_width
y_scale = pdf_height / image_height

left = bbox[0] * x_scale
right = bbox[2] * x_scale

top = pdf_height - (bbox[1] * y_scale)
bottom = pdf_height - (bbox[3] * y_scale)

return left, bottom, right, top

def transform_from_pdf_coords(bbox, pdf_height):
left = bbox[0]
right = bbox[2]

pypdf_top = pdf_height - bbox[1]
pypdf_bottom = pdf_height - bbox[3]

return left, pypdf_bottom, right, pypdf_top

def fill_pdf_form(input_pdf_path, fields_json_path, output_pdf_path):

with open(fields_json_path, "r") as f:
fields_data = json.load(f)

reader = PdfReader(input_pdf_path)
writer = PdfWriter()

writer.append(reader)

pdf_dimensions = {}
for i, page in enumerate(reader.pages):
mediabox = page.mediabox
pdf_dimensions[i + 1] = [mediabox.width, mediabox.height]

annotations = []
for field in fields_data["form_fields"]:
page_num = field["page_number"]

page_info = next(p for p in fields_data["pages"] if p["page_number"] == page_num)
pdf_width, pdf_height = pdf_dimensions[page_num]

if "pdf_width" in page_info:
transformed_entry_box = transform_from_pdf_coords(
field["entry_bounding_box"],
float(pdf_height)
)
else:
image_width = page_info["image_width"]
image_height = page_info["image_height"]
transformed_entry_box = transform_from_image_coords(
field["entry_bounding_box"],
image_width, image_height,
float(pdf_width), float(pdf_height)
)

if "entry_text" not in field or "text" not in field["entry_text"]:
continue
entry_text = field["entry_text"]
text = entry_text["text"]
if not text:
continue

font_name = entry_text.get("font", "Arial")
font_size = str(entry_text.get("font_size", 14)) + "pt"
font_color = entry_text.get("font_color", "000000")

annotation = FreeText(
text=text,
rect=transformed_entry_box,
font=font_name,
font_size=font_size,
font_color=font_color,
border_color=None,
background_color=None,
)
annotations.append(annotation)
writer.add_annotation(page_number=page_num - 1, annotation=annotation)

with open(output_pdf_path, "wb") as output:
writer.write(output)

print(f"Successfully filled PDF form and saved to {output_pdf_path}")
print(f"Added {len(annotations)} text annotations")

if __name__ == "__main__":
if len(sys.argv) != 4:
print("Usage: fill_pdf_form_with_annotations.py [input pdf] [fields.json] [output pdf]")
sys.exit(1)
input_pdf = sys.argv[1]
fields_json = sys.argv[2]
output_pdf = sys.argv[3]

fill_pdf_form(input_pdf, fields_json, output_pdf)
```

## See in GitHub

[See in GitHub](https://github.com/anthropics/skills/tree/main/pdf)

---

# Pptx Skill - Create PowerPoint Decks with Claude
URL: http://www.claudeskills.org/docs/skills-cases/pptx
Description: How the Pptx skill lets Claude build and edit PowerPoint presentations: layouts, speaker notes, and slide generation - full skill breakdown.
Source: Content adapted from anthropics/skills (MIT).

## Quick Reference

| Task | Guide |
|------|-------|
| Read/analyze content | `python -m markitdown presentation.pptx` |
| Edit or create from template | Read [editing.md](editing.md) |
| Create from scratch | Read [pptxgenjs.md](pptxgenjs.md) |

---

## Reading Content

```bash
# Text extraction
python -m markitdown presentation.pptx

# Visual overview
python scripts/thumbnail.py presentation.pptx

# Raw XML
python scripts/office/unpack.py presentation.pptx unpacked/
```

---

## Editing Workflow

**Read [editing.md](editing.md) for full details.**

1. Analyze template with `thumbnail.py`
2. Unpack -> manipulate slides -> edit content -> clean -> pack

---

## Creating from Scratch

**Read [pptxgenjs.md](pptxgenjs.md) for full details.**

Use when no template or reference presentation is available.

---

## Design Ideas

**Don't create boring slides.** Plain bullets on a white background won't impress anyone. Consider ideas from this list for each slide.

### Before Starting

- **Pick a bold, content-informed color palette**: The palette should feel designed for THIS topic. If swapping your colors into a completely different presentation would still "work," you haven't made specific enough choices.
- **Dominance over equality**: One color should dominate (60-70% visual weight), with 1-2 supporting tones and one sharp accent. Never give all colors equal weight.
- **Dark/light contrast**: Dark backgrounds for title + conclusion slides, light for content ("sandwich" structure). Or commit to dark throughout for a premium feel.
- **Commit to a visual motif**: Pick ONE distinctive element and repeat it - rounded image frames, icons in colored circles, thick single-side borders. Carry it across every slide.

### Color Palettes

Choose colors that match your topic - don't default to generic blue. Use these palettes as inspiration:

| Theme | Primary | Secondary | Accent |
|-------|---------|-----------|--------|
| **Midnight Executive** | `1E2761` (navy) | `CADCFC` (ice blue) | `FFFFFF` (white) |
| **Forest & Moss** | `2C5F2D` (forest) | `97BC62` (moss) | `F5F5F5` (cream) |
| **Coral Energy** | `F96167` (coral) | `F9E795` (gold) | `2F3C7E` (navy) |
| **Warm Terracotta** | `B85042` (terracotta) | `E7E8D1` (sand) | `A7BEAE` (sage) |
| **Ocean Gradient** | `065A82` (deep blue) | `1C7293` (teal) | `21295C` (midnight) |
| **Charcoal Minimal** | `36454F` (charcoal) | `F2F2F2` (off-white) | `212121` (black) |
| **Teal Trust** | `028090` (teal) | `00A896` (seafoam) | `02C39A` (mint) |
| **Berry & Cream** | `6D2E46` (berry) | `A26769` (dusty rose) | `ECE2D0` (cream) |
| **Sage Calm** | `84B59F` (sage) | `69A297` (eucalyptus) | `50808E` (slate) |
| **Cherry Bold** | `990011` (cherry) | `FCF6F5` (off-white) | `2F3C7E` (navy) |

### For Each Slide

**Every slide needs a visual element** - image, chart, icon, or shape. Text-only slides are forgettable.

**Layout options:**
- Two-column (text left, illustration on right)
- Icon + text rows (icon in colored circle, bold header, description below)
- 2x2 or 2x3 grid (image on one side, grid of content blocks on other)
- Half-bleed image (full left or right side) with content overlay

**Data display:**
- Large stat callouts (big numbers 60-72pt with small labels below)
- Comparison columns (before/after, pros/cons, side-by-side options)
- Timeline or process flow (numbered steps, arrows)

**Visual polish:**
- Icons in small colored circles next to section headers
- Italic accent text for key stats or taglines

### Typography

**Choose an interesting font pairing** - don't default to Arial. Pick a header font with personality and pair it with a clean body font.

| Header Font | Body Font |
|-------------|-----------|
| Georgia | Calibri |
| Arial Black | Arial |
| Calibri | Calibri Light |
| Cambria | Calibri |
| Trebuchet MS | Calibri |
| Impact | Arial |
| Palatino | Garamond |
| Consolas | Calibri |

| Element | Size |
|---------|------|
| Slide title | 36-44pt bold |
| Section header | 20-24pt bold |
| Body text | 14-16pt |
| Captions | 10-12pt muted |

### Spacing

- 0.5" minimum margins
- 0.3-0.5" between content blocks
- Leave breathing room-don't fill every inch

### Avoid (Common Mistakes)

- **Don't repeat the same layout** - vary columns, cards, and callouts across slides
- **Don't center body text** - left-align paragraphs and lists; center only titles
- **Don't skimp on size contrast** - titles need 36pt+ to stand out from 14-16pt body
- **Don't default to blue** - pick colors that reflect the specific topic
- **Don't mix spacing randomly** - choose 0.3" or 0.5" gaps and use consistently
- **Don't style one slide and leave the rest plain** - commit fully or keep it simple throughout
- **Don't create text-only slides** - add images, icons, charts, or visual elements; avoid plain title + bullets
- **Don't forget text box padding** - when aligning lines or shapes with text edges, set `margin: 0` on the text box or offset the shape to account for padding
- **Don't use low-contrast elements** - icons AND text need strong contrast against the background; avoid light text on light backgrounds or dark text on dark backgrounds
- **NEVER use accent lines under titles** - these are a hallmark of AI-generated slides; use whitespace or background color instead

---

## QA (Required)

**Assume there are problems. Your job is to find them.**

Your first render is almost never correct. Approach QA as a bug hunt, not a confirmation step. If you found zero issues on first inspection, you weren't looking hard enough.

### Content QA

```bash
python -m markitdown output.pptx
```

Check for missing content, typos, wrong order.

**When using templates, check for leftover placeholder text:**

```bash
python -m markitdown output.pptx | grep -iE "xxxx|lorem|ipsum|this.*(page|slide).*layout"
```

If grep returns results, fix them before declaring success.

### Visual QA

** USE SUBAGENTS** - even for 2-3 slides. You've been staring at the code and will see what you expect, not what's there. Subagents have fresh eyes.

Convert slides to images (see [Converting to Images](#converting-to-images)), then use this prompt:

```
Visually inspect these slides. Assume there are issues - find them.

Look for:
- Overlapping elements (text through shapes, lines through words, stacked elements)
- Text overflow or cut off at edges/box boundaries
- Decorative lines positioned for single-line text but title wrapped to two lines
- Source citations or footers colliding with content above
- Elements too close (< 0.3" gaps) or cards/sections nearly touching
- Uneven gaps (large empty area in one place, cramped in another)
- Insufficient margin from slide edges (< 0.5")
- Columns or similar elements not aligned consistently
- Low-contrast text (e.g., light gray text on cream-colored background)
- Low-contrast icons (e.g., dark icons on dark backgrounds without a contrasting circle)
- Text boxes too narrow causing excessive wrapping
- Leftover placeholder content

For each slide, list issues or areas of concern, even if minor.

Read and analyze these images:
1. /path/to/slide-01.jpg (Expected: [brief description])
2. /path/to/slide-02.jpg (Expected: [brief description])

Report ALL issues found, including minor ones.
```

### Verification Loop

1. Generate slides -> Convert to images -> Inspect
2. **List issues found** (if none found, look again more critically)
3. Fix issues
4. **Re-verify affected slides** - one fix often creates another problem
5. Repeat until a full pass reveals no new issues

**Do not declare success until you've completed at least one fix-and-verify cycle.**

---

## Converting to Images

Convert presentations to individual slide images for visual inspection:

```bash
python scripts/office/soffice.py --headless --convert-to pdf output.pptx
pdftoppm -jpeg -r 150 output.pdf slide
```

This creates `slide-01.jpg`, `slide-02.jpg`, etc.

To re-render specific slides after fixes:

```bash
pdftoppm -jpeg -r 150 -f N -l N output.pdf slide-fixed
```

---

## Dependencies

- `pip install "markitdown[pptx]"` - text extraction
- `pip install Pillow` - thumbnail grids
- `npm install -g pptxgenjs` - creating from scratch
- LibreOffice (`soffice`) - PDF conversion (auto-configured for sandboxed environments via `scripts/office/soffice.py`)
- Poppler (`pdftoppm`) - PDF to images

## Resource Files

### LICENSE.txt

[Download LICENSE.txt](/skills/pptx/LICENSE.txt)

_Binary resource_

### editing.md

[Download editing.md](/skills/pptx/editing.md)

_Binary resource_

### pptxgenjs.md

[Download pptxgenjs.md](/skills/pptx/pptxgenjs.md)

_Binary resource_

### scripts/__init__.py

[Download scripts/__init__.py](/skills/pptx/scripts/__init__.py)

_Binary resource_

### scripts/add_slide.py

[Download scripts/add_slide.py](/skills/pptx/scripts/add_slide.py)

_Binary resource_

### scripts/clean.py

[Download scripts/clean.py](/skills/pptx/scripts/clean.py)

_Binary resource_

### scripts/office/helpers/__init__.py

[Download scripts/office/helpers/__init__.py](/skills/pptx/scripts/office/helpers/__init__.py)

_Binary resource_

### scripts/office/helpers/merge_runs.py

[Download scripts/office/helpers/merge_runs.py](/skills/pptx/scripts/office/helpers/merge_runs.py)

```python
"""Merge adjacent runs with identical formatting in DOCX.

Merges adjacent elements that have identical properties.
Works on runs in paragraphs and inside tracked changes (, ).

Also:
- Removes rsid attributes from runs (revision metadata that doesn't affect rendering)
- Removes proofErr elements (spell/grammar markers that block merging)
"""

from pathlib import Path

import defusedxml.minidom

def merge_runs(input_dir: str) -> tuple[int, str]:
doc_xml = Path(input_dir) / "word" / "document.xml"

if not doc_xml.exists():
return 0, f"Error: {doc_xml} not found"

try:
dom = defusedxml.minidom.parseString(doc_xml.read_text(encoding="utf-8"))
root = dom.documentElement

_remove_elements(root, "proofErr")
_strip_run_rsid_attrs(root)

containers = {run.parentNode for run in _find_elements(root, "r")}

merge_count = 0
for container in containers:
merge_count += _merge_runs_in(container)

doc_xml.write_bytes(dom.toxml(encoding="UTF-8"))
return merge_count, f"Merged {merge_count} runs"

except Exception as e:
return 0, f"Error: {e}"

def _find_elements(root, tag: str) -> list:
results = []

def traverse(node):
if node.nodeType == node.ELEMENT_NODE:
name = node.localName or node.tagName
if name == tag or name.endswith(f":{tag}"):
results.append(node)
for child in node.childNodes:
traverse(child)

traverse(root)
return results

def _get_child(parent, tag: str):
for child in parent.childNodes:
if child.nodeType == child.ELEMENT_NODE:
name = child.localName or child.tagName
if name == tag or name.endswith(f":{tag}"):
return child
return None

def _get_children(parent, tag: str) -> list:
results = []
for child in parent.childNodes:
if child.nodeType == child.ELEMENT_NODE:
name = child.localName or child.tagName
if name == tag or name.endswith(f":{tag}"):
results.append(child)
return results

def _is_adjacent(elem1, elem2) -> bool:
node = elem1.nextSibling
while node:
if node == elem2:
return True
if node.nodeType == node.ELEMENT_NODE:
return False
if node.nodeType == node.TEXT_NODE and node.data.strip():
return False
node = node.nextSibling
return False

def _remove_elements(root, tag: str):
for elem in _find_elements(root, tag):
if elem.parentNode:
elem.parentNode.removeChild(elem)

def _strip_run_rsid_attrs(root):
for run in _find_elements(root, "r"):
for attr in list(run.attributes.values()):
if "rsid" in attr.name.lower():
run.removeAttribute(attr.name)

def _merge_runs_in(container) -> int:
merge_count = 0
run = _first_child_run(container)

while run:
while True:
next_elem = _next_element_sibling(run)
if next_elem and _is_run(next_elem) and _can_merge(run, next_elem):
_merge_run_content(run, next_elem)
container.removeChild(next_elem)
merge_count += 1
else:
break

_consolidate_text(run)
run = _next_sibling_run(run)

return merge_count

def _first_child_run(container):
for child in container.childNodes:
if child.nodeType == child.ELEMENT_NODE and _is_run(child):
return child
return None

def _next_element_sibling(node):
sibling = node.nextSibling
while sibling:
if sibling.nodeType == sibling.ELEMENT_NODE:
return sibling
sibling = sibling.nextSibling
return None

def _next_sibling_run(node):
sibling = node.nextSibling
while sibling:
if sibling.nodeType == sibling.ELEMENT_NODE:
if _is_run(sibling):
return sibling
sibling = sibling.nextSibling
return None

def _is_run(node) -> bool:
name = node.localName or node.tagName
return name == "r" or name.endswith(":r")

def _can_merge(run1, run2) -> bool:
rpr1 = _get_child(run1, "rPr")
rpr2 = _get_child(run2, "rPr")

if (rpr1 is None) != (rpr2 is None):
return False
if rpr1 is None:
return True
return rpr1.toxml() == rpr2.toxml()

def _merge_run_content(target, source):
for child in list(source.childNodes):
if child.nodeType == child.ELEMENT_NODE:
name = child.localName or child.tagName
if name != "rPr" and not name.endswith(":rPr"):
target.appendChild(child)

def _consolidate_text(run):
t_elements = _get_children(run, "t")

for i in range(len(t_elements) - 1, 0, -1):
curr, prev = t_elements[i], t_elements[i - 1]

if _is_adjacent(prev, curr):
prev_text = prev.firstChild.data if prev.firstChild else ""
curr_text = curr.firstChild.data if curr.firstChild else ""
merged = prev_text + curr_text

if prev.firstChild:
prev.firstChild.data = merged
else:
prev.appendChild(run.ownerDocument.createTextNode(merged))

if merged.startswith(" ") or merged.endswith(" "):
prev.setAttribute("xml:space", "preserve")
elif prev.hasAttribute("xml:space"):
prev.removeAttribute("xml:space")

run.removeChild(curr)
```

### scripts/office/helpers/simplify_redlines.py

[Download scripts/office/helpers/simplify_redlines.py](/skills/pptx/scripts/office/helpers/simplify_redlines.py)

```python
"""Simplify tracked changes by merging adjacent w:ins or w:del elements.

Merges adjacent elements from the same author into a single element.
Same for elements. This makes heavily-redlined documents easier to
work with by reducing the number of tracked change wrappers.

Rules:
- Only merges w:ins with w:ins, w:del with w:del (same element type)
- Only merges if same author (ignores timestamp differences)
- Only merges if truly adjacent (only whitespace between them)
"""

import xml.etree.ElementTree as ET
import zipfile
from pathlib import Path

import defusedxml.minidom

WORD_NS = "http://schemas.openxmlformats.org/wordprocessingml/2006/main"

def simplify_redlines(input_dir: str) -> tuple[int, str]:
doc_xml = Path(input_dir) / "word" / "document.xml"

if not doc_xml.exists():
return 0, f"Error: {doc_xml} not found"

try:
dom = defusedxml.minidom.parseString(doc_xml.read_text(encoding="utf-8"))
root = dom.documentElement

merge_count = 0

containers = _find_elements(root, "p") + _find_elements(root, "tc")

for container in containers:
merge_count += _merge_tracked_changes_in(container, "ins")
merge_count += _merge_tracked_changes_in(container, "del")

doc_xml.write_bytes(dom.toxml(encoding="UTF-8"))
return merge_count, f"Simplified {merge_count} tracked changes"

except Exception as e:
return 0, f"Error: {e}"

def _merge_tracked_changes_in(container, tag: str) -> int:
merge_count = 0

tracked = [
child
for child in container.childNodes
if child.nodeType == child.ELEMENT_NODE and _is_element(child, tag)
]

if len(tracked) < 2:
return 0

i = 0
while i < len(tracked) - 1:
curr = tracked[i]
next_elem = tracked[i + 1]

if _can_merge_tracked(curr, next_elem):
_merge_tracked_content(curr, next_elem)
container.removeChild(next_elem)
tracked.pop(i + 1)
merge_count += 1
else:
i += 1

return merge_count

def _is_element(node, tag: str) -> bool:
name = node.localName or node.tagName
return name == tag or name.endswith(f":{tag}")

def _get_author(elem) -> str:
author = elem.getAttribute("w:author")
if not author:
for attr in elem.attributes.values():
if attr.localName == "author" or attr.name.endswith(":author"):
return attr.value
return author

def _can_merge_tracked(elem1, elem2) -> bool:
if _get_author(elem1) != _get_author(elem2):
return False

node = elem1.nextSibling
while node and node != elem2:
if node.nodeType == node.ELEMENT_NODE:
return False
if node.nodeType == node.TEXT_NODE and node.data.strip():
return False
node = node.nextSibling

return True

def _merge_tracked_content(target, source):
while source.firstChild:
child = source.firstChild
source.removeChild(child)
target.appendChild(child)

def _find_elements(root, tag: str) -> list:
results = []

def traverse(node):
if node.nodeType == node.ELEMENT_NODE:
name = node.localName or node.tagName
if name == tag or name.endswith(f":{tag}"):
results.append(node)
for child in node.childNodes:
traverse(child)

traverse(root)
return results

def get_tracked_change_authors(doc_xml_path: Path) -> dict[str, int]:
if not doc_xml_path.exists():
return {}

try:
tree = ET.parse(doc_xml_path)
root = tree.getroot()
except ET.ParseError:
return {}

namespaces = {"w": WORD_NS}
author_attr = f"{{{WORD_NS}}}author"

authors: dict[str, int] = {}
for tag in ["ins", "del"]:
for elem in root.findall(f".//w:{tag}", namespaces):
author = elem.get(author_attr)
if author:
authors[author] = authors.get(author, 0) + 1

return authors

def _get_authors_from_docx(docx_path: Path) -> dict[str, int]:
try:
with zipfile.ZipFile(docx_path, "r") as zf:
if "word/document.xml" not in zf.namelist():
return {}
with zf.open("word/document.xml") as f:
tree = ET.parse(f)
root = tree.getroot()

namespaces = {"w": WORD_NS}
author_attr = f"{{{WORD_NS}}}author"

authors: dict[str, int] = {}
for tag in ["ins", "del"]:
for elem in root.findall(f".//w:{tag}", namespaces):
author = elem.get(author_attr)
if author:
authors[author] = authors.get(author, 0) + 1
return authors
except (zipfile.BadZipFile, ET.ParseError):
return {}

def infer_author(modified_dir: Path, original_docx: Path, default: str = "Claude") -> str:
modified_xml = modified_dir / "word" / "document.xml"
modified_authors = get_tracked_change_authors(modified_xml)

if not modified_authors:
return default

original_authors = _get_authors_from_docx(original_docx)

new_changes: dict[str, int] = {}
for author, count in modified_authors.items():
original_count = original_authors.get(author, 0)
diff = count - original_count
if diff > 0:
new_changes[author] = diff

if not new_changes:
return default

if len(new_changes) == 1:
return next(iter(new_changes))

raise ValueError(
f"Multiple authors added new changes: {new_changes}. "
"Cannot infer which author to validate."
)
```

### scripts/office/pack.py

[Download scripts/office/pack.py](/skills/pptx/scripts/office/pack.py)

```python
"""Pack a directory into a DOCX, PPTX, or XLSX file.

Validates with auto-repair, condenses XML formatting, and creates the Office file.

Usage:
python pack.py [--original ] [--validate true|false]

Examples:
python pack.py unpacked/ output.docx --original input.docx
python pack.py unpacked/ output.pptx --validate false
"""

import argparse
import sys
import shutil
import tempfile
import zipfile
from pathlib import Path

import defusedxml.minidom

from validators import DOCXSchemaValidator, PPTXSchemaValidator, RedliningValidator

def pack(
input_directory: str,
output_file: str,
original_file: str | None = None,
validate: bool = True,
infer_author_func=None,
) -> tuple[None, str]:
input_dir = Path(input_directory)
output_path = Path(output_file)
suffix = output_path.suffix.lower()

if not input_dir.is_dir():
return None, f"Error: {input_dir} is not a directory"

if suffix not in {".docx", ".pptx", ".xlsx"}:
return None, f"Error: {output_file} must be a .docx, .pptx, or .xlsx file"

if validate and original_file:
original_path = Path(original_file)
if original_path.exists():
success, output = _run_validation(
input_dir, original_path, suffix, infer_author_func
)
if output:
print(output)
if not success:
return None, f"Error: Validation failed for {input_dir}"

with tempfile.TemporaryDirectory() as temp_dir:
temp_content_dir = Path(temp_dir) / "content"
shutil.copytree(input_dir, temp_content_dir)

for pattern in ["*.xml", "*.rels"]:
for xml_file in temp_content_dir.rglob(pattern):
_condense_xml(xml_file)

output_path.parent.mkdir(parents=True, exist_ok=True)
with zipfile.ZipFile(output_path, "w", zipfile.ZIP_DEFLATED) as zf:
for f in temp_content_dir.rglob("*"):
if f.is_file():
zf.write(f, f.relative_to(temp_content_dir))

return None, f"Successfully packed {input_dir} to {output_file}"

def _run_validation(
unpacked_dir: Path,
original_file: Path,
suffix: str,
infer_author_func=None,
) -> tuple[bool, str | None]:
output_lines = []
validators = []

if suffix == ".docx":
author = "Claude"
if infer_author_func:
try:
author = infer_author_func(unpacked_dir, original_file)
except ValueError as e:
print(f"Warning: {e} Using default author 'Claude'.", file=sys.stderr)

validators = [
DOCXSchemaValidator(unpacked_dir, original_file),
RedliningValidator(unpacked_dir, original_file, author=author),
]
elif suffix == ".pptx":
validators = [PPTXSchemaValidator(unpacked_dir, original_file)]

if not validators:
return True, None

total_repairs = sum(v.repair() for v in validators)
if total_repairs:
output_lines.append(f"Auto-repaired {total_repairs} issue(s)")

success = all(v.validate() for v in validators)

if success:
output_lines.append("All validations PASSED!")

return success, "\n".join(output_lines) if output_lines else None

def _condense_xml(xml_file: Path) -> None:
try:
with open(xml_file, encoding="utf-8") as f:
dom = defusedxml.minidom.parse(f)

for element in dom.getElementsByTagName("*"):
if element.tagName.endswith(":t"):
continue

for child in list(element.childNodes):
if (
child.nodeType == child.TEXT_NODE
and child.nodeValue
and child.nodeValue.strip() == ""
) or child.nodeType == child.COMMENT_NODE:
element.removeChild(child)

xml_file.write_bytes(dom.toxml(encoding="UTF-8"))
except Exception as e:
print(f"ERROR: Failed to parse {xml_file.name}: {e}", file=sys.stderr)
raise

if __name__ == "__main__":
parser = argparse.ArgumentParser(
description="Pack a directory into a DOCX, PPTX, or XLSX file"
)
parser.add_argument("input_directory", help="Unpacked Office document directory")
parser.add_argument("output_file", help="Output Office file (.docx/.pptx/.xlsx)")
parser.add_argument(
"--original",
help="Original file for validation comparison",
)
parser.add_argument(
"--validate",
type=lambda x: x.lower() == "true",
default=True,
metavar="true|false",
help="Run validation with auto-repair (default: true)",
)
args = parser.parse_args()

_, message = pack(
args.input_directory,
args.output_file,
original_file=args.original,
validate=args.validate,
)
print(message)

if "Error" in message:
sys.exit(1)
```

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-chart.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-chart.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-chart.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-chartDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-chartDrawing.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-chartDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-diagram.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-diagram.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-diagram.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-lockedCanvas.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-lockedCanvas.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-lockedCanvas.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-main.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-main.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-main.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-picture.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-picture.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-picture.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-spreadsheetDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-spreadsheetDrawing.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-spreadsheetDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-wordprocessingDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-wordprocessingDrawing.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-wordprocessingDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/pml.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/pml.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/pml.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-additionalCharacteristics.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-additionalCharacteristics.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-additionalCharacteristics.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-bibliography.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-bibliography.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-bibliography.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-commonSimpleTypes.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-commonSimpleTypes.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-commonSimpleTypes.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-customXmlDataProperties.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-customXmlDataProperties.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-customXmlDataProperties.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-customXmlSchemaProperties.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-customXmlSchemaProperties.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-customXmlSchemaProperties.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesCustom.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesCustom.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesCustom.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesExtended.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesExtended.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesExtended.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesVariantTypes.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesVariantTypes.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesVariantTypes.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-math.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-math.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-math.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-relationshipReference.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-relationshipReference.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-relationshipReference.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/sml.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/sml.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/sml.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/vml-main.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/vml-main.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/vml-main.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/vml-officeDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/vml-officeDrawing.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/vml-officeDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/vml-presentationDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/vml-presentationDrawing.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/vml-presentationDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/vml-spreadsheetDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/vml-spreadsheetDrawing.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/vml-spreadsheetDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/vml-wordprocessingDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/vml-wordprocessingDrawing.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/vml-wordprocessingDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/wml.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/wml.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/wml.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/xml.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/xml.xsd](/skills/pptx/scripts/office/schemas/ISO-IEC29500-4_2016/xml.xsd)

_Binary resource_

### scripts/office/schemas/ecma/fouth-edition/opc-contentTypes.xsd

[Download scripts/office/schemas/ecma/fouth-edition/opc-contentTypes.xsd](/skills/pptx/scripts/office/schemas/ecma/fouth-edition/opc-contentTypes.xsd)

_Binary resource_

### scripts/office/schemas/ecma/fouth-edition/opc-coreProperties.xsd

[Download scripts/office/schemas/ecma/fouth-edition/opc-coreProperties.xsd](/skills/pptx/scripts/office/schemas/ecma/fouth-edition/opc-coreProperties.xsd)

_Binary resource_

### scripts/office/schemas/ecma/fouth-edition/opc-digSig.xsd

[Download scripts/office/schemas/ecma/fouth-edition/opc-digSig.xsd](/skills/pptx/scripts/office/schemas/ecma/fouth-edition/opc-digSig.xsd)

_Binary resource_

### scripts/office/schemas/ecma/fouth-edition/opc-relationships.xsd

[Download scripts/office/schemas/ecma/fouth-edition/opc-relationships.xsd](/skills/pptx/scripts/office/schemas/ecma/fouth-edition/opc-relationships.xsd)

_Binary resource_

### scripts/office/schemas/mce/mc.xsd

[Download scripts/office/schemas/mce/mc.xsd](/skills/pptx/scripts/office/schemas/mce/mc.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-2010.xsd

[Download scripts/office/schemas/microsoft/wml-2010.xsd](/skills/pptx/scripts/office/schemas/microsoft/wml-2010.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-2012.xsd

[Download scripts/office/schemas/microsoft/wml-2012.xsd](/skills/pptx/scripts/office/schemas/microsoft/wml-2012.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-2018.xsd

[Download scripts/office/schemas/microsoft/wml-2018.xsd](/skills/pptx/scripts/office/schemas/microsoft/wml-2018.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-cex-2018.xsd

[Download scripts/office/schemas/microsoft/wml-cex-2018.xsd](/skills/pptx/scripts/office/schemas/microsoft/wml-cex-2018.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-cid-2016.xsd

[Download scripts/office/schemas/microsoft/wml-cid-2016.xsd](/skills/pptx/scripts/office/schemas/microsoft/wml-cid-2016.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-sdtdatahash-2020.xsd

[Download scripts/office/schemas/microsoft/wml-sdtdatahash-2020.xsd](/skills/pptx/scripts/office/schemas/microsoft/wml-sdtdatahash-2020.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-symex-2015.xsd

[Download scripts/office/schemas/microsoft/wml-symex-2015.xsd](/skills/pptx/scripts/office/schemas/microsoft/wml-symex-2015.xsd)

_Binary resource_

### scripts/office/soffice.py

[Download scripts/office/soffice.py](/skills/pptx/scripts/office/soffice.py)

```python
"""
Helper for running LibreOffice (soffice) in environments where AF_UNIX
sockets may be blocked (e.g., sandboxed VMs). Detects the restriction
at runtime and applies an LD_PRELOAD shim if needed.

Usage:
from office.soffice import run_soffice, get_soffice_env

# Option 1 – run soffice directly
result = run_soffice(["--headless", "--convert-to", "pdf", "input.docx"])

# Option 2 – get env dict for your own subprocess calls
env = get_soffice_env()
subprocess.run(["soffice", ...], env=env)
"""

import os
import socket
import subprocess
import tempfile
from pathlib import Path

def get_soffice_env() -> dict:
env = os.environ.copy()
env["SAL_USE_VCLPLUGIN"] = "svp"

if _needs_shim():
shim = _ensure_shim()
env["LD_PRELOAD"] = str(shim)

return env

def run_soffice(args: list[str], **kwargs) -> subprocess.CompletedProcess:
env = get_soffice_env()
return subprocess.run(["soffice"] + args, env=env, **kwargs)

_SHIM_SO = Path(tempfile.gettempdir()) / "lo_socket_shim.so"

def _needs_shim() -> bool:
try:
s = socket.socket(socket.AF_UNIX, socket.SOCK_STREAM)
s.close()
return False
except OSError:
return True

def _ensure_shim() -> Path:
if _SHIM_SO.exists():
return _SHIM_SO

src = Path(tempfile.gettempdir()) / "lo_socket_shim.c"
src.write_text(_SHIM_SOURCE)
subprocess.run(
["gcc", "-shared", "-fPIC", "-o", str(_SHIM_SO), str(src), "-ldl"],
check=True,
capture_output=True,
)
src.unlink()
return _SHIM_SO

_SHIM_SOURCE = r"""
#define _GNU_SOURCE
#include
#include
#include
#include
#include
#include
#include

static int (*real_socket)(int, int, int);
static int (*real_socketpair)(int, int, int, int[2]);
static int (*real_listen)(int, int);
static int (*real_accept)(int, struct sockaddr *, socklen_t *);
static int (*real_close)(int);
static int (*real_read)(int, void *, size_t);

/* Per-FD bookkeeping (FDs >= 1024 are passed through unshimmed). */
static int is_shimmed[1024];
static int peer_of[1024];
static int wake_r[1024]; /* accept() blocks reading this */
static int wake_w[1024]; /* close() writes to this */
static int listener_fd = -1; /* FD that received listen() */

__attribute__((constructor))
static void init(void) {
real_socket = dlsym(RTLD_NEXT, "socket");
real_socketpair = dlsym(RTLD_NEXT, "socketpair");
real_listen = dlsym(RTLD_NEXT, "listen");
real_accept = dlsym(RTLD_NEXT, "accept");
real_close = dlsym(RTLD_NEXT, "close");
real_read = dlsym(RTLD_NEXT, "read");
for (int i = 0; i < 1024; i++) {
peer_of[i] = -1;
wake_r[i] = -1;
wake_w[i] = -1;
}
}

/* ---- socket ---------------------------------------------------------- */
int socket(int domain, int type, int protocol) {
if (domain == AF_UNIX) {
int fd = real_socket(domain, type, protocol);
if (fd >= 0) return fd;
/* socket(AF_UNIX) blocked – fall back to socketpair(). */
int sv[2];
if (real_socketpair(domain, type, protocol, sv) == 0) {
if (sv[0] >= 0 && sv[0] < 1024) {
is_shimmed[sv[0]] = 1;
peer_of[sv[0]] = sv[1];
int wp[2];
if (pipe(wp) == 0) {
wake_r[sv[0]] = wp[0];
wake_w[sv[0]] = wp[1];
}
}
return sv[0];
}
errno = EPERM;
return -1;
}
return real_socket(domain, type, protocol);
}

/* ---- listen ---------------------------------------------------------- */
int listen(int sockfd, int backlog) {
if (sockfd >= 0 && sockfd < 1024 && is_shimmed[sockfd]) {
listener_fd = sockfd;
return 0;
}
return real_listen(sockfd, backlog);
}

/* ---- accept ---------------------------------------------------------- */
int accept(int sockfd, struct sockaddr *addr, socklen_t *addrlen) {
if (sockfd >= 0 && sockfd < 1024 && is_shimmed[sockfd]) {
/* Block until close() writes to the wake pipe. */
if (wake_r[sockfd] >= 0) {
char buf;
real_read(wake_r[sockfd], &buf, 1);
}
errno = ECONNABORTED;
return -1;
}
return real_accept(sockfd, addr, addrlen);
}

/* ---- close ----------------------------------------------------------- */
int close(int fd) {
if (fd >= 0 && fd < 1024 && is_shimmed[fd]) {
int was_listener = (fd == listener_fd);
is_shimmed[fd] = 0;

if (wake_w[fd] >= 0) { /* unblock accept() */
char c = 0;
write(wake_w[fd], &c, 1);
real_close(wake_w[fd]);
wake_w[fd] = -1;
}
if (wake_r[fd] >= 0) { real_close(wake_r[fd]); wake_r[fd] = -1; }
if (peer_of[fd] >= 0) { real_close(peer_of[fd]); peer_of[fd] = -1; }

if (was_listener)
_exit(0); /* conversion done – exit */
}
return real_close(fd);
}
"""

if __name__ == "__main__":
import sys
result = run_soffice(sys.argv[1:])
sys.exit(result.returncode)
```

### scripts/office/unpack.py

[Download scripts/office/unpack.py](/skills/pptx/scripts/office/unpack.py)

```python
"""Unpack Office files (DOCX, PPTX, XLSX) for editing.

Extracts the ZIP archive, pretty-prints XML files, and optionally:
- Merges adjacent runs with identical formatting (DOCX only)
- Simplifies adjacent tracked changes from same author (DOCX only)

Usage:
python unpack.py [options]

Examples:
python unpack.py document.docx unpacked/
python unpack.py presentation.pptx unpacked/
python unpack.py document.docx unpacked/ --merge-runs false
"""

import argparse
import sys
import zipfile
from pathlib import Path

import defusedxml.minidom

from helpers.merge_runs import merge_runs as do_merge_runs
from helpers.simplify_redlines import simplify_redlines as do_simplify_redlines

SMART_QUOTE_REPLACEMENTS = {
"\u201c": "“",
"\u201d": "”",
"\u2018": "‘",
"\u2019": "’",
}

def unpack(
input_file: str,
output_directory: str,
merge_runs: bool = True,
simplify_redlines: bool = True,
) -> tuple[None, str]:
input_path = Path(input_file)
output_path = Path(output_directory)
suffix = input_path.suffix.lower()

if not input_path.exists():
return None, f"Error: {input_file} does not exist"

if suffix not in {".docx", ".pptx", ".xlsx"}:
return None, f"Error: {input_file} must be a .docx, .pptx, or .xlsx file"

try:
output_path.mkdir(parents=True, exist_ok=True)

with zipfile.ZipFile(input_path, "r") as zf:
zf.extractall(output_path)

xml_files = list(output_path.rglob("*.xml")) + list(output_path.rglob("*.rels"))
for xml_file in xml_files:
_pretty_print_xml(xml_file)

message = f"Unpacked {input_file} ({len(xml_files)} XML files)"

if suffix == ".docx":
if simplify_redlines:
simplify_count, _ = do_simplify_redlines(str(output_path))
message += f", simplified {simplify_count} tracked changes"

if merge_runs:
merge_count, _ = do_merge_runs(str(output_path))
message += f", merged {merge_count} runs"

for xml_file in xml_files:
_escape_smart_quotes(xml_file)

return None, message

except zipfile.BadZipFile:
return None, f"Error: {input_file} is not a valid Office file"
except Exception as e:
return None, f"Error unpacking: {e}"

def _pretty_print_xml(xml_file: Path) -> None:
try:
content = xml_file.read_text(encoding="utf-8")
dom = defusedxml.minidom.parseString(content)
xml_file.write_bytes(dom.toprettyxml(indent=" ", encoding="utf-8"))
except Exception:
pass

def _escape_smart_quotes(xml_file: Path) -> None:
try:
content = xml_file.read_text(encoding="utf-8")
for char, entity in SMART_QUOTE_REPLACEMENTS.items():
content = content.replace(char, entity)
xml_file.write_text(content, encoding="utf-8")
except Exception:
pass

if __name__ == "__main__":
parser = argparse.ArgumentParser(
description="Unpack an Office file (DOCX, PPTX, XLSX) for editing"
)
parser.add_argument("input_file", help="Office file to unpack")
parser.add_argument("output_directory", help="Output directory")
parser.add_argument(
"--merge-runs",
type=lambda x: x.lower() == "true",
default=True,
metavar="true|false",
help="Merge adjacent runs with identical formatting (DOCX only, default: true)",
)
parser.add_argument(
"--simplify-redlines",
type=lambda x: x.lower() == "true",
default=True,
metavar="true|false",
help="Merge adjacent tracked changes from same author (DOCX only, default: true)",
)
args = parser.parse_args()

_, message = unpack(
args.input_file,
args.output_directory,
merge_runs=args.merge_runs,
simplify_redlines=args.simplify_redlines,
)
print(message)

if "Error" in message:
sys.exit(1)
```

### scripts/office/validate.py

[Download scripts/office/validate.py](/skills/pptx/scripts/office/validate.py)

```python
"""
Command line tool to validate Office document XML files against XSD schemas and tracked changes.

Usage:
python validate.py [--original ] [--auto-repair] [--author NAME]

The first argument can be either:
- An unpacked directory containing the Office document XML files
- A packed Office file (.docx/.pptx/.xlsx) which will be unpacked to a temp directory

Auto-repair fixes:
- paraId/durableId values that exceed OOXML limits
- Missing xml:space="preserve" on w:t elements with whitespace
"""

import argparse
import sys
import tempfile
import zipfile
from pathlib import Path

from validators import DOCXSchemaValidator, PPTXSchemaValidator, RedliningValidator

def main():
parser = argparse.ArgumentParser(description="Validate Office document XML files")
parser.add_argument(
"path",
help="Path to unpacked directory or packed Office file (.docx/.pptx/.xlsx)",
)
parser.add_argument(
"--original",
required=False,
default=None,
help="Path to original file (.docx/.pptx/.xlsx). If omitted, all XSD errors are reported and redlining validation is skipped.",
)
parser.add_argument(
"-v",
"--verbose",
action="store_true",
help="Enable verbose output",
)
parser.add_argument(
"--auto-repair",
action="store_true",
help="Automatically repair common issues (hex IDs, whitespace preservation)",
)
parser.add_argument(
"--author",
default="Claude",
help="Author name for redlining validation (default: Claude)",
)
args = parser.parse_args()

path = Path(args.path)
assert path.exists(), f"Error: {path} does not exist"

original_file = None
if args.original:
original_file = Path(args.original)
assert original_file.is_file(), f"Error: {original_file} is not a file"
assert original_file.suffix.lower() in [".docx", ".pptx", ".xlsx"], (
f"Error: {original_file} must be a .docx, .pptx, or .xlsx file"
)

file_extension = (original_file or path).suffix.lower()
assert file_extension in [".docx", ".pptx", ".xlsx"], (
f"Error: Cannot determine file type from {path}. Use --original or provide a .docx/.pptx/.xlsx file."
)

if path.is_file() and path.suffix.lower() in [".docx", ".pptx", ".xlsx"]:
temp_dir = tempfile.mkdtemp()
with zipfile.ZipFile(path, "r") as zf:
zf.extractall(temp_dir)
unpacked_dir = Path(temp_dir)
else:
assert path.is_dir(), f"Error: {path} is not a directory or Office file"
unpacked_dir = path

match file_extension:
case ".docx":
validators = [
DOCXSchemaValidator(unpacked_dir, original_file, verbose=args.verbose),
]
if original_file:
validators.append(
RedliningValidator(unpacked_dir, original_file, verbose=args.verbose, author=args.author)
)
case ".pptx":
validators = [
PPTXSchemaValidator(unpacked_dir, original_file, verbose=args.verbose),
]
case _:
print(f"Error: Validation not supported for file type {file_extension}")
sys.exit(1)

if args.auto_repair:
total_repairs = sum(v.repair() for v in validators)
if total_repairs:
print(f"Auto-repaired {total_repairs} issue(s)")

success = all(v.validate() for v in validators)

if success:
print("All validations PASSED!")

sys.exit(0 if success else 1)

if __name__ == "__main__":
main()
```

### scripts/office/validators/__init__.py

[Download scripts/office/validators/__init__.py](/skills/pptx/scripts/office/validators/__init__.py)

```python
"""
Validation modules for Word document processing.
"""

from .base import BaseSchemaValidator
from .docx import DOCXSchemaValidator
from .pptx import PPTXSchemaValidator
from .redlining import RedliningValidator

__all__ = [
"BaseSchemaValidator",
"DOCXSchemaValidator",
"PPTXSchemaValidator",
"RedliningValidator",
]
```

### scripts/office/validators/base.py

[Download scripts/office/validators/base.py](/skills/pptx/scripts/office/validators/base.py)

_Binary resource_

### scripts/office/validators/docx.py

[Download scripts/office/validators/docx.py](/skills/pptx/scripts/office/validators/docx.py)

_Binary resource_

### scripts/office/validators/pptx.py

[Download scripts/office/validators/pptx.py](/skills/pptx/scripts/office/validators/pptx.py)

_Binary resource_

### scripts/office/validators/redlining.py

[Download scripts/office/validators/redlining.py](/skills/pptx/scripts/office/validators/redlining.py)

_Binary resource_

### scripts/thumbnail.py

[Download scripts/thumbnail.py](/skills/pptx/scripts/thumbnail.py)

_Binary resource_

## See in GitHub

[See in GitHub](https://github.com/anthropics/skills/tree/main/pptx)

---

# Skill Creator - The Claude Skill That Builds Skills
URL: http://www.claudeskills.org/docs/skills-cases/skill-creator
Description: How the Skill Creator skill helps Claude scaffold new agent skills: interviews, structure, and packaging - the meta-skill explained.
Source: Content adapted from anthropics/skills (MIT).

A skill for creating new skills and iteratively improving them.

At a high level, the process of creating a skill goes like this:

- Decide what you want the skill to do and roughly how it should do it
- Write a draft of the skill
- Create a few test prompts and run claude-with-access-to-the-skill on them
- Help the user evaluate the results both qualitatively and quantitatively
- While the runs happen in the background, draft some quantitative evals if there aren't any (if there are some, you can either use as is or modify if you feel something needs to change about them). Then explain them to the user (or if they already existed, explain the ones that already exist)
- Use the `eval-viewer/generate_review.py` script to show the user the results for them to look at, and also let them look at the quantitative metrics
- Rewrite the skill based on feedback from the user's evaluation of the results (and also if there are any glaring flaws that become apparent from the quantitative benchmarks)
- Repeat until you're satisfied
- Expand the test set and try again at larger scale

Your job when using this skill is to figure out where the user is in this process and then jump in and help them progress through these stages. So for instance, maybe they're like "I want to make a skill for X". You can help narrow down what they mean, write a draft, write the test cases, figure out how they want to evaluate, run all the prompts, and repeat.

On the other hand, maybe they already have a draft of the skill. In this case you can go straight to the eval/iterate part of the loop.

Of course, you should always be flexible and if the user is like "I don't need to run a bunch of evaluations, just vibe with me", you can do that instead.

Then after the skill is done (but again, the order is flexible), you can also run the skill description improver, which we have a whole separate script for, to optimize the triggering of the skill.

Cool? Cool.

## Communicating with the user

The skill creator is liable to be used by people across a wide range of familiarity with coding jargon. If you haven't heard (and how could you, it's only very recently that it started), there's a trend now where the power of Claude is inspiring plumbers to open up their terminals, parents and grandparents to google "how to install npm". On the other hand, the bulk of users are probably fairly computer-literate.

So please pay attention to context cues to understand how to phrase your communication! In the default case, just to give you some idea:

- "evaluation" and "benchmark" are borderline, but OK
- for "JSON" and "assertion" you want to see serious cues from the user that they know what those things are before using them without explaining them

It's OK to briefly explain terms if you're in doubt, and feel free to clarify terms with a short definition if you're unsure if the user will get it.

---

## Creating a skill

### Capture Intent

Start by understanding the user's intent. The current conversation might already contain a workflow the user wants to capture (e.g., they say "turn this into a skill"). If so, extract answers from the conversation history first - the tools used, the sequence of steps, corrections the user made, input/output formats observed. The user may need to fill the gaps, and should confirm before proceeding to the next step.

1. What should this skill enable Claude to do?
2. When should this skill trigger? (what user phrases/contexts)
3. What's the expected output format?
4. Should we set up test cases to verify the skill works? Skills with objectively verifiable outputs (file transforms, data extraction, code generation, fixed workflow steps) benefit from test cases. Skills with subjective outputs (writing style, art) often don't need them. Suggest the appropriate default based on the skill type, but let the user decide.

### Interview and Research

Proactively ask questions about edge cases, input/output formats, example files, success criteria, and dependencies. Wait to write test prompts until you've got this part ironed out.

Check available MCPs - if useful for research (searching docs, finding similar skills, looking up best practices), research in parallel via subagents if available, otherwise inline. Come prepared with context to reduce burden on the user.

### Write the SKILL.md

Based on the user interview, fill in these components:

- **name**: Skill identifier
- **description**: When to trigger, what it does. This is the primary triggering mechanism - include both what the skill does AND specific contexts for when to use it. All "when to use" info goes here, not in the body. Note: currently Claude has a tendency to "undertrigger" skills -- to not use them when they'd be useful. To combat this, please make the skill descriptions a little bit "pushy". So for instance, instead of "How to build a simple fast dashboard to display internal Anthropic data.", you might write "How to build a simple fast dashboard to display internal Anthropic data. Make sure to use this skill whenever the user mentions dashboards, data visualization, internal metrics, or wants to display any kind of company data, even if they don't explicitly ask for a 'dashboard.'"
- **compatibility**: Required tools, dependencies (optional, rarely needed)
- **the rest of the skill :)**

### Skill Writing Guide

#### Anatomy of a Skill

```
skill-name/
SKILL.md (required)
YAML frontmatter (name, description required)
Markdown instructions
Bundled Resources (optional)
scripts/ - Executable code for deterministic/repetitive tasks
references/ - Docs loaded into context as needed
assets/ - Files used in output (templates, icons, fonts)
```

#### Progressive Disclosure

Skills use a three-level loading system:
1. **Metadata** (name + description) - Always in context (~100 words)
2. **SKILL.md body** - In context whenever skill triggers (<500 lines ideal)
3. **Bundled resources** - As needed (unlimited, scripts can execute without loading)

These word counts are approximate and you can feel free to go longer if needed.

**Key patterns:**
- Keep SKILL.md under 500 lines; if you're approaching this limit, add an additional layer of hierarchy along with clear pointers about where the model using the skill should go next to follow up.
- Reference files clearly from SKILL.md with guidance on when to read them
- For large reference files (>300 lines), include a table of contents

**Domain organization**: When a skill supports multiple domains/frameworks, organize by variant:
```
cloud-deploy/
SKILL.md (workflow + selection)
references/
aws.md
gcp.md
azure.md
```
Claude reads only the relevant reference file.

#### Principle of Lack of Surprise

This goes without saying, but skills must not contain malware, exploit code, or any content that could compromise system security. A skill's contents should not surprise the user in their intent if described. Don't go along with requests to create misleading skills or skills designed to facilitate unauthorized access, data exfiltration, or other malicious activities. Things like a "roleplay as an XYZ" are OK though.

#### Writing Patterns

Prefer using the imperative form in instructions.

**Defining output formats** - You can do it like this:
```markdown
## Report structure
ALWAYS use this exact template:
# [Title]
## Executive summary
## Key findings
## Recommendations
```

**Examples pattern** - It's useful to include examples. You can format them like this (but if "Input" and "Output" are in the examples you might want to deviate a little):
```markdown
## Commit message format
**Example 1:**
Input: Added user authentication with JWT tokens
Output: feat(auth): implement JWT-based authentication
```

### Writing Style

Try to explain to the model why things are important in lieu of heavy-handed musty MUSTs. Use theory of mind and try to make the skill general and not super-narrow to specific examples. Start by writing a draft and then look at it with fresh eyes and improve it.

### Test Cases

After writing the skill draft, come up with 2-3 realistic test prompts - the kind of thing a real user would actually say. Share them with the user: [you don't have to use this exact language] "Here are a few test cases I'd like to try. Do these look right, or do you want to add more?" Then run them.

Save test cases to `evals/evals.json`. Don't write assertions yet - just the prompts. You'll draft assertions in the next step while the runs are in progress.

```json
{
"skill_name": "example-skill",
"evals": [
{
"id": 1,
"prompt": "User's task prompt",
"expected_output": "Description of expected result",
"files": []
}
]
}
```

See `references/schemas.md` for the full schema (including the `assertions` field, which you'll add later).

## Running and evaluating test cases

This section is one continuous sequence - don't stop partway through. Do NOT use `/skill-test` or any other testing skill.

Put results in `<skill-name>-workspace/` as a sibling to the skill directory. Within the workspace, organize results by iteration (`iteration-1/`, `iteration-2/`, etc.) and within that, each test case gets a directory (`eval-0/`, `eval-1/`, etc.). Don't create all of this upfront - just create directories as you go.

### Step 1: Spawn all runs (with-skill AND baseline) in the same turn

For each test case, spawn two subagents in the same turn - one with the skill, one without. This is important: don't spawn the with-skill runs first and then come back for baselines later. Launch everything at once so it all finishes around the same time.

**With-skill run:**

```
Execute this task:
- Skill path:
- Task:
- Input files:
- Save outputs to: /iteration-/eval-/with_skill/outputs/
- Outputs to save:
```

**Baseline run** (same prompt, but the baseline depends on context):
- **Creating a new skill**: no skill at all. Same prompt, no skill path, save to `without_skill/outputs/`.
- **Improving an existing skill**: the old version. Before editing, snapshot the skill (`cp -r <skill-path> <workspace>/skill-snapshot/`), then point the baseline subagent at the snapshot. Save to `old_skill/outputs/`.

Write an `eval_metadata.json` for each test case (assertions can be empty for now). Give each eval a descriptive name based on what it's testing - not just "eval-0". Use this name for the directory too. If this iteration uses new or modified eval prompts, create these files for each new eval directory - don't assume they carry over from previous iterations.

```json
{
"eval_id": 0,
"eval_name": "descriptive-name-here",
"prompt": "The user's task prompt",
"assertions": []
}
```

### Step 2: While runs are in progress, draft assertions

Don't just wait for the runs to finish - you can use this time productively. Draft quantitative assertions for each test case and explain them to the user. If assertions already exist in `evals/evals.json`, review them and explain what they check.

Good assertions are objectively verifiable and have descriptive names - they should read clearly in the benchmark viewer so someone glancing at the results immediately understands what each one checks. Subjective skills (writing style, design quality) are better evaluated qualitatively - don't force assertions onto things that need human judgment.

Update the `eval_metadata.json` files and `evals/evals.json` with the assertions once drafted. Also explain to the user what they'll see in the viewer - both the qualitative outputs and the quantitative benchmark.

### Step 3: As runs complete, capture timing data

When each subagent task completes, you receive a notification containing `total_tokens` and `duration_ms`. Save this data immediately to `timing.json` in the run directory:

```json
{
"total_tokens": 84852,
"duration_ms": 23332,
"total_duration_seconds": 23.3
}
```

This is the only opportunity to capture this data - it comes through the task notification and isn't persisted elsewhere. Process each notification as it arrives rather than trying to batch them.

### Step 4: Grade, aggregate, and launch the viewer

Once all runs are done:

1. **Grade each run** - spawn a grader subagent (or grade inline) that reads `agents/grader.md` and evaluates each assertion against the outputs. Save results to `grading.json` in each run directory. The grading.json expectations array must use the fields `text`, `passed`, and `evidence` (not `name`/`met`/`details` or other variants) - the viewer depends on these exact field names. For assertions that can be checked programmatically, write and run a script rather than eyeballing it - scripts are faster, more reliable, and can be reused across iterations.

2. **Aggregate into benchmark** - run the aggregation script from the skill-creator directory:
```bash
python -m scripts.aggregate_benchmark /iteration-N --skill-name
```
This produces `benchmark.json` and `benchmark.md` with pass_rate, time, and tokens for each configuration, with mean stddev and the delta. If generating benchmark.json manually, see `references/schemas.md` for the exact schema the viewer expects.
Put each with_skill version before its baseline counterpart.

3. **Do an analyst pass** - read the benchmark data and surface patterns the aggregate stats might hide. See `agents/analyzer.md` (the "Analyzing Benchmark Results" section) for what to look for - things like assertions that always pass regardless of skill (non-discriminating), high-variance evals (possibly flaky), and time/token tradeoffs.

4. **Launch the viewer** with both qualitative outputs and quantitative data:
```bash
nohup python /eval-viewer/generate_review.py \
/iteration-N \
--skill-name "my-skill" \
--benchmark /iteration-N/benchmark.json \
> /dev/null 2>&1 &
VIEWER_PID=$!
```
For iteration 2+, also pass `--previous-workspace <workspace>/iteration-<N-1>`.

**Cowork / headless environments:** If `webbrowser.open()` is not available or the environment has no display, use `--static <output_path>` to write a standalone HTML file instead of starting a server. Feedback will be downloaded as a `feedback.json` file when the user clicks "Submit All Reviews". After download, copy `feedback.json` into the workspace directory for the next iteration to pick up.

Note: please use generate_review.py to create the viewer; there's no need to write custom HTML.

5. **Tell the user** something like: "I've opened the results in your browser. There are two tabs - 'Outputs' lets you click through each test case and leave feedback, 'Benchmark' shows the quantitative comparison. When you're done, come back here and let me know."

### What the user sees in the viewer

The "Outputs" tab shows one test case at a time:
- **Prompt**: the task that was given
- **Output**: the files the skill produced, rendered inline where possible
- **Previous Output** (iteration 2+): collapsed section showing last iteration's output
- **Formal Grades** (if grading was run): collapsed section showing assertion pass/fail
- **Feedback**: a textbox that auto-saves as they type
- **Previous Feedback** (iteration 2+): their comments from last time, shown below the textbox

The "Benchmark" tab shows the stats summary: pass rates, timing, and token usage for each configuration, with per-eval breakdowns and analyst observations.

Navigation is via prev/next buttons or arrow keys. When done, they click "Submit All Reviews" which saves all feedback to `feedback.json`.

### Step 5: Read the feedback

When the user tells you they're done, read `feedback.json`:

```json
{
"reviews": [
{"run_id": "eval-0-with_skill", "feedback": "the chart is missing axis labels", "timestamp": "..."},
{"run_id": "eval-1-with_skill", "feedback": "", "timestamp": "..."},
{"run_id": "eval-2-with_skill", "feedback": "perfect, love this", "timestamp": "..."}
],
"status": "complete"
}
```

Empty feedback means the user thought it was fine. Focus your improvements on the test cases where the user had specific complaints.

Kill the viewer server when you're done with it:

```bash
kill $VIEWER_PID 2>/dev/null
```

---

## Improving the skill

This is the heart of the loop. You've run the test cases, the user has reviewed the results, and now you need to make the skill better based on their feedback.

### How to think about improvements

1. **Generalize from the feedback.** The big picture thing that's happening here is that we're trying to create skills that can be used a million times (maybe literally, maybe even more who knows) across many different prompts. Here you and the user are iterating on only a few examples over and over again because it helps move faster. The user knows these examples in and out and it's quick for them to assess new outputs. But if the skill you and the user are codeveloping works only for those examples, it's useless. Rather than put in fiddly overfitty changes, or oppressively constrictive MUSTs, if there's some stubborn issue, you might try branching out and using different metaphors, or recommending different patterns of working. It's relatively cheap to try and maybe you'll land on something great.

2. **Keep the prompt lean.** Remove things that aren't pulling their weight. Make sure to read the transcripts, not just the final outputs - if it looks like the skill is making the model waste a bunch of time doing things that are unproductive, you can try getting rid of the parts of the skill that are making it do that and seeing what happens.

3. **Explain the why.** Try hard to explain the **why** behind everything you're asking the model to do. Today's LLMs are *smart*. They have good theory of mind and when given a good harness can go beyond rote instructions and really make things happen. Even if the feedback from the user is terse or frustrated, try to actually understand the task and why the user is writing what they wrote, and what they actually wrote, and then transmit this understanding into the instructions. If you find yourself writing ALWAYS or NEVER in all caps, or using super rigid structures, that's a yellow flag - if possible, reframe and explain the reasoning so that the model understands why the thing you're asking for is important. That's a more humane, powerful, and effective approach.

4. **Look for repeated work across test cases.** Read the transcripts from the test runs and notice if the subagents all independently wrote similar helper scripts or took the same multi-step approach to something. If all 3 test cases resulted in the subagent writing a `create_docx.py` or a `build_chart.py`, that's a strong signal the skill should bundle that script. Write it once, put it in `scripts/`, and tell the skill to use it. This saves every future invocation from reinventing the wheel.

This task is pretty important (we are trying to create billions a year in economic value here!) and your thinking time is not the blocker; take your time and really mull things over. I'd suggest writing a draft revision and then looking at it anew and making improvements. Really do your best to get into the head of the user and understand what they want and need.

### The iteration loop

After improving the skill:

1. Apply your improvements to the skill
2. Rerun all test cases into a new `iteration-<N+1>/` directory, including baseline runs. If you're creating a new skill, the baseline is always `without_skill` (no skill) - that stays the same across iterations. If you're improving an existing skill, use your judgment on what makes sense as the baseline: the original version the user came in with, or the previous iteration.
3. Launch the reviewer with `--previous-workspace` pointing at the previous iteration
4. Wait for the user to review and tell you they're done
5. Read the new feedback, improve again, repeat

Keep going until:
- The user says they're happy
- The feedback is all empty (everything looks good)
- You're not making meaningful progress

---

## Advanced: Blind comparison

For situations where you want a more rigorous comparison between two versions of a skill (e.g., the user asks "is the new version actually better?"), there's a blind comparison system. Read `agents/comparator.md` and `agents/analyzer.md` for the details. The basic idea is: give two outputs to an independent agent without telling it which is which, and let it judge quality. Then analyze why the winner won.

This is optional, requires subagents, and most users won't need it. The human review loop is usually sufficient.

---

## Description Optimization

The description field in SKILL.md frontmatter is the primary mechanism that determines whether Claude invokes a skill. After creating or improving a skill, offer to optimize the description for better triggering accuracy.

### Step 1: Generate trigger eval queries

Create 20 eval queries - a mix of should-trigger and should-not-trigger. Save as JSON:

```json
[
{"query": "the user prompt", "should_trigger": true},
{"query": "another prompt", "should_trigger": false}
]
```

The queries must be realistic and something a Claude Code or Claude.ai user would actually type. Not abstract requests, but requests that are concrete and specific and have a good amount of detail. For instance, file paths, personal context about the user's job or situation, column names and values, company names, URLs. A little bit of backstory. Some might be in lowercase or contain abbreviations or typos or casual speech. Use a mix of different lengths, and focus on edge cases rather than making them clear-cut (the user will get a chance to sign off on them).

Bad: `"Format this data"`, `"Extract text from PDF"`, `"Create a chart"`

Good: `"ok so my boss just sent me this xlsx file (its in my downloads, called something like 'Q4 sales final FINAL v2.xlsx') and she wants me to add a column that shows the profit margin as a percentage. The revenue is in column C and costs are in column D i think"`

For the **should-trigger** queries (8-10), think about coverage. You want different phrasings of the same intent - some formal, some casual. Include cases where the user doesn't explicitly name the skill or file type but clearly needs it. Throw in some uncommon use cases and cases where this skill competes with another but should win.

For the **should-not-trigger** queries (8-10), the most valuable ones are the near-misses - queries that share keywords or concepts with the skill but actually need something different. Think adjacent domains, ambiguous phrasing where a naive keyword match would trigger but shouldn't, and cases where the query touches on something the skill does but in a context where another tool is more appropriate.

The key thing to avoid: don't make should-not-trigger queries obviously irrelevant. "Write a fibonacci function" as a negative test for a PDF skill is too easy - it doesn't test anything. The negative cases should be genuinely tricky.

### Step 2: Review with user

Present the eval set to the user for review using the HTML template:

1. Read the template from `assets/eval_review.html`
2. Replace the placeholders:
- `__EVAL_DATA_PLACEHOLDER__` -> the JSON array of eval items (no quotes around it - it's a JS variable assignment)
- `__SKILL_NAME_PLACEHOLDER__` -> the skill's name
- `__SKILL_DESCRIPTION_PLACEHOLDER__` -> the skill's current description
3. Write to a temp file (e.g., `/tmp/eval_review_<skill-name>.html`) and open it: `open /tmp/eval_review_<skill-name>.html`
4. The user can edit queries, toggle should-trigger, add/remove entries, then click "Export Eval Set"
5. The file downloads to `~/Downloads/eval_set.json` - check the Downloads folder for the most recent version in case there are multiple (e.g., `eval_set (1).json`)

This step matters - bad eval queries lead to bad descriptions.

### Step 3: Run the optimization loop

Tell the user: "This will take some time - I'll run the optimization loop in the background and check on it periodically."

Save the eval set to the workspace, then run in the background:

```bash
python -m scripts.run_loop \
--eval-set \
--skill-path \
--model \
--max-iterations 5 \
--verbose
```

Use the model ID from your system prompt (the one powering the current session) so the triggering test matches what the user actually experiences.

While it runs, periodically tail the output to give the user updates on which iteration it's on and what the scores look like.

This handles the full optimization loop automatically. It splits the eval set into 60% train and 40% held-out test, evaluates the current description (running each query 3 times to get a reliable trigger rate), then calls Claude to propose improvements based on what failed. It re-evaluates each new description on both train and test, iterating up to 5 times. When it's done, it opens an HTML report in the browser showing the results per iteration and returns JSON with `best_description` - selected by test score rather than train score to avoid overfitting.

### How skill triggering works

Understanding the triggering mechanism helps design better eval queries. Skills appear in Claude's `available_skills` list with their name + description, and Claude decides whether to consult a skill based on that description. The important thing to know is that Claude only consults skills for tasks it can't easily handle on its own - simple, one-step queries like "read this PDF" may not trigger a skill even if the description matches perfectly, because Claude can handle them directly with basic tools. Complex, multi-step, or specialized queries reliably trigger skills when the description matches.

This means your eval queries should be substantive enough that Claude would actually benefit from consulting a skill. Simple queries like "read file X" are poor test cases - they won't trigger skills regardless of description quality.

### Step 4: Apply the result

Take `best_description` from the JSON output and update the skill's SKILL.md frontmatter. Show the user before/after and report the scores.

---

### Package and Present (only if `present_files` tool is available)

Check whether you have access to the `present_files` tool. If you don't, skip this step. If you do, package the skill and present the .skill file to the user:

```bash
python -m scripts.package_skill
```

After packaging, direct the user to the resulting `.skill` file path so they can install it.

---

## Claude.ai-specific instructions

In Claude.ai, the core workflow is the same (draft -> test -> review -> improve -> repeat), but because Claude.ai doesn't have subagents, some mechanics change. Here's what to adapt:

**Running test cases**: No subagents means no parallel execution. For each test case, read the skill's SKILL.md, then follow its instructions to accomplish the test prompt yourself. Do them one at a time. This is less rigorous than independent subagents (you wrote the skill and you're also running it, so you have full context), but it's a useful sanity check - and the human review step compensates. Skip the baseline runs - just use the skill to complete the task as requested.

**Reviewing results**: If you can't open a browser (e.g., Claude.ai's VM has no display, or you're on a remote server), skip the browser reviewer entirely. Instead, present results directly in the conversation. For each test case, show the prompt and the output. If the output is a file the user needs to see (like a .docx or .xlsx), save it to the filesystem and tell them where it is so they can download and inspect it. Ask for feedback inline: "How does this look? Anything you'd change?"

**Benchmarking**: Skip the quantitative benchmarking - it relies on baseline comparisons which aren't meaningful without subagents. Focus on qualitative feedback from the user.

**The iteration loop**: Same as before - improve the skill, rerun the test cases, ask for feedback - just without the browser reviewer in the middle. You can still organize results into iteration directories on the filesystem if you have one.

**Description optimization**: This section requires the `claude` CLI tool (specifically `claude -p`) which is only available in Claude Code. Skip it if you're on Claude.ai.

**Blind comparison**: Requires subagents. Skip it.

**Packaging**: The `package_skill.py` script works anywhere with Python and a filesystem. On Claude.ai, you can run it and the user can download the resulting `.skill` file.

**Updating an existing skill**: The user might be asking you to update an existing skill, not create a new one. In this case:
- **Preserve the original name.** Note the skill's directory name and `name` frontmatter field -- use them unchanged. E.g., if the installed skill is `research-helper`, output `research-helper.skill` (not `research-helper-v2`).
- **Copy to a writeable location before editing.** The installed skill path may be read-only. Copy to `/tmp/skill-name/`, edit there, and package from the copy.
- **If packaging manually, stage in `/tmp/` first**, then copy to the output directory -- direct writes may fail due to permissions.

---

## Cowork-Specific Instructions

If you're in Cowork, the main things to know are:

- You have subagents, so the main workflow (spawn test cases in parallel, run baselines, grade, etc.) all works. (However, if you run into severe problems with timeouts, it's OK to run the test prompts in series rather than parallel.)
- You don't have a browser or display, so when generating the eval viewer, use `--static <output_path>` to write a standalone HTML file instead of starting a server. Then proffer a link that the user can click to open the HTML in their browser.
- For whatever reason, the Cowork setup seems to disincline Claude from generating the eval viewer after running the tests, so just to reiterate: whether you're in Cowork or in Claude Code, after running tests, you should always generate the eval viewer for the human to look at examples before revising the skill yourself and trying to make corrections, using `generate_review.py` (not writing your own boutique html code). Sorry in advance but I'm gonna go all caps here: GENERATE THE EVAL VIEWER *BEFORE* evaluating inputs yourself. You want to get them in front of the human ASAP!
- Feedback works differently: since there's no running server, the viewer's "Submit All Reviews" button will download `feedback.json` as a file. You can then read it from there (you may have to request access first).
- Packaging works - `package_skill.py` just needs Python and a filesystem.
- Description optimization (`run_loop.py` / `run_eval.py`) should work in Cowork just fine since it uses `claude -p` via subprocess, not a browser, but please save it until you've fully finished making the skill and the user agrees it's in good shape.
- **Updating an existing skill**: The user might be asking you to update an existing skill, not create a new one. Follow the update guidance in the claude.ai section above.

---

## Reference files

The agents/ directory contains instructions for specialized subagents. Read them when you need to spawn the relevant subagent.

- `agents/grader.md` - How to evaluate assertions against outputs
- `agents/comparator.md` - How to do blind A/B comparison between two outputs
- `agents/analyzer.md` - How to analyze why one version beat another

The references/ directory has additional documentation:
- `references/schemas.md` - JSON structures for evals.json, grading.json, etc.

---

Repeating one more time the core loop here for emphasis:

- Figure out what the skill is about
- Draft or edit the skill
- Run claude-with-access-to-the-skill on test prompts
- With the user, evaluate the outputs:
- Create benchmark.json and run `eval-viewer/generate_review.py` to help the user review them
- Run quantitative evals
- Repeat until you and the user are satisfied
- Package the final skill and return it to the user.

Please add steps to your TodoList, if you have such a thing, to make sure you don't forget. If you're in Cowork, please specifically put "Create evals JSON and run `eval-viewer/generate_review.py` so human can review test cases" in your TodoList to make sure it happens.

Good luck!

## Resource Files

### LICENSE.txt

[Download LICENSE.txt](/skills/skill-creator/LICENSE.txt)

_Binary resource_

### agents/analyzer.md

[Download agents/analyzer.md](/skills/skill-creator/agents/analyzer.md)

_Binary resource_

### agents/comparator.md

[Download agents/comparator.md](/skills/skill-creator/agents/comparator.md)

_Binary resource_

### agents/grader.md

[Download agents/grader.md](/skills/skill-creator/agents/grader.md)

_Binary resource_

### assets/eval_review.html

[Download assets/eval_review.html](/skills/skill-creator/assets/eval_review.html)

_Binary resource_

### eval-viewer/generate_review.py

[Download eval-viewer/generate_review.py](/skills/skill-creator/eval-viewer/generate_review.py)

_Binary resource_

### eval-viewer/viewer.html

[Download eval-viewer/viewer.html](/skills/skill-creator/eval-viewer/viewer.html)

_Binary resource_

### references/schemas.md

[Download references/schemas.md](/skills/skill-creator/references/schemas.md)

_Binary resource_

### scripts/__init__.py

[Download scripts/__init__.py](/skills/skill-creator/scripts/__init__.py)

_Binary resource_

### scripts/aggregate_benchmark.py

[Download scripts/aggregate_benchmark.py](/skills/skill-creator/scripts/aggregate_benchmark.py)

_Binary resource_

### scripts/generate_report.py

[Download scripts/generate_report.py](/skills/skill-creator/scripts/generate_report.py)

_Binary resource_

### scripts/improve_description.py

[Download scripts/improve_description.py](/skills/skill-creator/scripts/improve_description.py)

_Binary resource_

### scripts/package_skill.py

[Download scripts/package_skill.py](/skills/skill-creator/scripts/package_skill.py)

```python
#!/usr/bin/env python3
"""
Skill Packager - Creates a distributable .skill file of a skill folder

Usage:
python utils/package_skill.py [output-directory]

Example:
python utils/package_skill.py skills/public/my-skill
python utils/package_skill.py skills/public/my-skill ./dist
"""

import fnmatch
import sys
import zipfile
from pathlib import Path
from scripts.quick_validate import validate_skill

# Patterns to exclude when packaging skills.
EXCLUDE_DIRS = {"__pycache__", "node_modules"}
EXCLUDE_GLOBS = {"*.pyc"}
EXCLUDE_FILES = {".DS_Store"}
# Directories excluded only at the skill root (not when nested deeper).
ROOT_EXCLUDE_DIRS = {"evals"}

def should_exclude(rel_path: Path) -> bool:
"""Check if a path should be excluded from packaging."""
parts = rel_path.parts
if any(part in EXCLUDE_DIRS for part in parts):
return True
# rel_path is relative to skill_path.parent, so parts[0] is the skill
# folder name and parts[1] (if present) is the first subdir.
if len(parts) > 1 and parts[1] in ROOT_EXCLUDE_DIRS:
return True
name = rel_path.name
if name in EXCLUDE_FILES:
return True
return any(fnmatch.fnmatch(name, pat) for pat in EXCLUDE_GLOBS)

def package_skill(skill_path, output_dir=None):
"""
Package a skill folder into a .skill file.

Args:
skill_path: Path to the skill folder
output_dir: Optional output directory for the .skill file (defaults to current directory)

Returns:
Path to the created .skill file, or None if error
"""
skill_path = Path(skill_path).resolve()

# Validate skill folder exists
if not skill_path.exists():
print(f"❌ Error: Skill folder not found: {skill_path}")
return None

if not skill_path.is_dir():
print(f"❌ Error: Path is not a directory: {skill_path}")
return None

# Validate SKILL.md exists
skill_md = skill_path / "SKILL.md"
if not skill_md.exists():
print(f"❌ Error: SKILL.md not found in {skill_path}")
return None

# Run validation before packaging
print("🔍 Validating skill...")
valid, message = validate_skill(skill_path)
if not valid:
print(f"❌ Validation failed: {message}")
print(" Please fix the validation errors before packaging.")
return None
print(f"✅ {message}\n")

# Determine output location
skill_name = skill_path.name
if output_dir:
output_path = Path(output_dir).resolve()
output_path.mkdir(parents=True, exist_ok=True)
else:
output_path = Path.cwd()

skill_filename = output_path / f"{skill_name}.skill"

# Create the .skill file (zip format)
try:
with zipfile.ZipFile(skill_filename, 'w', zipfile.ZIP_DEFLATED) as zipf:
# Walk through the skill directory, excluding build artifacts
for file_path in skill_path.rglob('*'):
if not file_path.is_file():
continue
arcname = file_path.relative_to(skill_path.parent)
if should_exclude(arcname):
print(f" Skipped: {arcname}")
continue
zipf.write(file_path, arcname)
print(f" Added: {arcname}")

print(f"\n✅ Successfully packaged skill to: {skill_filename}")
return skill_filename

except Exception as e:
print(f"❌ Error creating .skill file: {e}")
return None

def main():
if len(sys.argv) < 2:
print("Usage: python utils/package_skill.py [output-directory]")
print("\nExample:")
print(" python utils/package_skill.py skills/public/my-skill")
print(" python utils/package_skill.py skills/public/my-skill ./dist")
sys.exit(1)

skill_path = sys.argv[1]
output_dir = sys.argv[2] if len(sys.argv) > 2 else None

print(f"📦 Packaging skill: {skill_path}")
if output_dir:
print(f" Output directory: {output_dir}")
print()

result = package_skill(skill_path, output_dir)

if result:
sys.exit(0)
else:
sys.exit(1)

if __name__ == "__main__":
main()
```

### scripts/quick_validate.py

[Download scripts/quick_validate.py](/skills/skill-creator/scripts/quick_validate.py)

```python
#!/usr/bin/env python3
"""
Quick validation script for skills - minimal version
"""

import sys
import os
import re
import yaml
from pathlib import Path

def validate_skill(skill_path):
"""Basic validation of a skill"""
skill_path = Path(skill_path)

# Check SKILL.md exists
skill_md = skill_path / 'SKILL.md'
if not skill_md.exists():
return False, "SKILL.md not found"

# Read and validate frontmatter
content = skill_md.read_text()
if not content.startswith('---'):
return False, "No YAML frontmatter found"

# Extract frontmatter
match = re.match(r'^---\n(.*?)\n---', content, re.DOTALL)
if not match:
return False, "Invalid frontmatter format"

frontmatter_text = match.group(1)

# Parse YAML frontmatter
try:
frontmatter = yaml.safe_load(frontmatter_text)
if not isinstance(frontmatter, dict):
return False, "Frontmatter must be a YAML dictionary"
except yaml.YAMLError as e:
return False, f"Invalid YAML in frontmatter: {e}"

# Define allowed properties
ALLOWED_PROPERTIES = {'name', 'description', 'license', 'allowed-tools', 'metadata', 'compatibility'}

# Check for unexpected properties (excluding nested keys under metadata)
unexpected_keys = set(frontmatter.keys()) - ALLOWED_PROPERTIES
if unexpected_keys:
return False, (
f"Unexpected key(s) in SKILL.md frontmatter: {', '.join(sorted(unexpected_keys))}. "
f"Allowed properties are: {', '.join(sorted(ALLOWED_PROPERTIES))}"
)

# Check required fields
if 'name' not in frontmatter:
return False, "Missing 'name' in frontmatter"
if 'description' not in frontmatter:
return False, "Missing 'description' in frontmatter"

# Extract name for validation
name = frontmatter.get('name', '')
if not isinstance(name, str):
return False, f"Name must be a string, got {type(name).__name__}"
name = name.strip()
if name:
# Check naming convention (kebab-case: lowercase with hyphens)
if not re.match(r'^[a-z0-9-]+$', name):
return False, f"Name '{name}' should be kebab-case (lowercase letters, digits, and hyphens only)"
if name.startswith('-') or name.endswith('-') or '--' in name:
return False, f"Name '{name}' cannot start/end with hyphen or contain consecutive hyphens"
# Check name length (max 64 characters per spec)
if len(name) > 64:
return False, f"Name is too long ({len(name)} characters). Maximum is 64 characters."

# Extract and validate description
description = frontmatter.get('description', '')
if not isinstance(description, str):
return False, f"Description must be a string, got {type(description).__name__}"
description = description.strip()
if description:
# Check for angle brackets
if '<' in description or '>' in description:
return False, "Description cannot contain angle brackets (< or >)"
# Check description length (max 1024 characters per spec)
if len(description) > 1024:
return False, f"Description is too long ({len(description)} characters). Maximum is 1024 characters."

# Validate compatibility field if present (optional)
compatibility = frontmatter.get('compatibility', '')
if compatibility:
if not isinstance(compatibility, str):
return False, f"Compatibility must be a string, got {type(compatibility).__name__}"
if len(compatibility) > 500:
return False, f"Compatibility is too long ({len(compatibility)} characters). Maximum is 500 characters."

return True, "Skill is valid!"

if __name__ == "__main__":
if len(sys.argv) != 2:
print("Usage: python quick_validate.py ")
sys.exit(1)

valid, message = validate_skill(sys.argv[1])
print(message)
sys.exit(0 if valid else 1)
```

### scripts/run_eval.py

[Download scripts/run_eval.py](/skills/skill-creator/scripts/run_eval.py)

_Binary resource_

### scripts/run_loop.py

[Download scripts/run_loop.py](/skills/skill-creator/scripts/run_loop.py)

_Binary resource_

### scripts/utils.py

[Download scripts/utils.py](/skills/skill-creator/scripts/utils.py)

```python
"""Shared utilities for skill-creator scripts."""

from pathlib import Path

def parse_skill_md(skill_path: Path) -> tuple[str, str, str]:
"""Parse a SKILL.md file, returning (name, description, full_content)."""
content = (skill_path / "SKILL.md").read_text()
lines = content.split("\n")

if lines[0].strip() != "---":
raise ValueError("SKILL.md missing frontmatter (no opening ---)")

end_idx = None
for i, line in enumerate(lines[1:], start=1):
if line.strip() == "---":
end_idx = i
break

if end_idx is None:
raise ValueError("SKILL.md missing frontmatter (no closing ---)")

name = ""
description = ""
frontmatter_lines = lines[1:end_idx]
i = 0
while i < len(frontmatter_lines):
line = frontmatter_lines[i]
if line.startswith("name:"):
name = line[len("name:"):].strip().strip('"').strip("'")
elif line.startswith("description:"):
value = line[len("description:"):].strip()
# Handle YAML multiline indicators (>, |, >-, |-)
if value in (">", "|", ">-", "|-"):
continuation_lines: list[str] = []
i += 1
while i < len(frontmatter_lines) and (frontmatter_lines[i].startswith(" ") or frontmatter_lines[i].startswith("\t")):
continuation_lines.append(frontmatter_lines[i].strip())
i += 1
description = " ".join(continuation_lines)
continue
else:
description = value.strip('"').strip("'")
i += 1

return name, description, content
```

## See in GitHub

[See in GitHub](https://github.com/anthropics/skills/tree/main/skill-creator)

---

# Slack GIF Creator Skill - Custom GIFs with Claude
URL: http://www.claudeskills.org/docs/skills-cases/slack-gif-creator
Description: How the Slack GIF Creator skill generates reaction GIFs sized for Slack with animation presets - full skill walkthrough.
Source: Content adapted from [anthropics/skills](https://github.com/anthropics/skills) (MIT). Last synced July 8, 2026, against the April 20, 2026 upstream update.

## Overview

The official description: *"Knowledge and utilities for creating animated GIFs optimized for Slack. Provides constraints, validation tools, and animation concepts. Use when users request animated GIFs for Slack like 'make me a GIF of X doing Y for Slack.'"*

## How the skill works

The SKILL.md pairs Slack's hard requirements (dimensions, file size) with a small Python animation toolkit:

- **Core workflow** - draw graphics (from scratch or from user-uploaded images), compose frames, build the GIF, validate against Slack constraints
- **`core.gif_builder`** - GIFBuilder assembles frames into a compliant GIF
- **`core.validators`** - checks size and dimension limits before you ship
- **`core.easing` + `core.frame_composer`** - easing functions and frame helpers for smooth motion
- **Animation concepts** - named recipes like shake/vibrate and pulse/heartbeat that map user requests to concrete frame math

## What's inside the skill folder

- `core/gif_builder.py`, `core/validators.py`, `core/easing.py`, `core/frame_composer.py`
- `requirements.txt`, `SKILL.md`, `LICENSE.txt`

## Key takeaways for your own skills

- **Constraints first**: encoding the platform's limits as a validator means output is correct by construction, not by luck.
- Naming animation concepts ("pulse", "shake") gives users a vocabulary the skill can reliably map to code.

## See it on GitHub

[skills/slack-gif-creator](https://github.com/anthropics/skills/tree/main/skills/slack-gif-creator)

---

# Claude Skill Template - Structure & Boilerplate Explained
URL: http://www.claudeskills.org/docs/skills-cases/template-skill
Description: A reusable Claude skill template: SKILL.md structure, frontmatter, trigger description, and resources - copy it to build your own agent skill.
Source: Content adapted from anthropics/skills (MIT).

## See in GitHub

[See in GitHub](https://github.com/anthropics/skills/tree/main/template)

---

# Theme Factory - Claude Skill for Artifact Themes
URL: http://www.claudeskills.org/docs/skills-cases/theme-factory
Description: The Theme Factory skill applies polished visual themes to Claude artifacts: palettes, fonts, and styling presets - see how it works inside.
Source: Content adapted from [anthropics/skills](https://github.com/anthropics/skills) (MIT). Last synced July 8, 2026, against the April 20, 2026 upstream update.

## Overview

The official description: *"Toolkit for styling artifacts with a theme. These artifacts can be slides, docs, reports, HTML landing pages, etc. There are 10 pre-set themes with colors/fonts that you can apply to any artifact that has been created, or can generate a new theme on-the-fly."*

## How the skill works

The workflow is deliberately simple: pick (or generate) a theme, then apply its palette and type pairing to whatever artifact Claude just built. The SKILL.md covers usage instructions, the theme catalog, per-theme details, the application process, and how to create a custom theme when none of the presets fit.

## The 10 built-in themes

Each theme ships as its own markdown spec under `themes/`:

`arctic-frost`, `botanical-garden`, `desert-rose`, `forest-canopy`, `golden-hour`, `midnight-galaxy`, `modern-minimalist`, `ocean-depths`, `sunset-boulevard` - plus a showcase PDF (`theme-showcase.pdf`) that previews them side by side.

## What's inside the skill folder

- `SKILL.md` - selection and application logic
- `themes/*.md` - 10 theme specs (colors, fonts, styling notes)
- `theme-showcase.pdf` - visual preview of every preset
- `LICENSE.txt`

## Key takeaways for your own skills

- Shipping **data as files** (10 theme specs) instead of inlining everything keeps the skill's context footprint small - Claude loads only the theme it needs.
- A visual showcase asset lets users choose by looking rather than reading hex values.

## See it on GitHub

[skills/theme-factory](https://github.com/anthropics/skills/tree/main/skills/theme-factory)

---

# Webapp Testing Skill - Browser Testing with Claude
URL: http://www.claudeskills.org/docs/skills-cases/webapp-testing
Description: The Webapp Testing skill lets Claude drive a browser with Playwright: click flows, screenshots, and debugging - full SKILL.md explained.
Source: Content adapted from [anthropics/skills](https://github.com/anthropics/skills) (MIT). Last synced July 8, 2026, against the April 20, 2026 upstream update.

## Overview

The official description: *"Toolkit for interacting with and testing local web applications using Playwright. Supports verifying frontend functionality, debugging UI behavior, capturing browser screenshots, and viewing browser logs."*

## How the skill works

The SKILL.md is organized around a **decision tree**: Claude first chooses the right approach for the task (static HTML vs a running dev server vs an already-running app), then applies a **reconnaissance-then-action pattern** - discover elements and state first, act second. It also documents the most common pitfall (acting on elements before the page settles) and a set of best practices for stable automation.

The centerpiece utility is `scripts/with_server.py`, which starts your dev server, waits until it is ready, runs the Playwright interaction, and tears everything down cleanly.

## What's inside the skill folder

- `scripts/with_server.py` - server lifecycle wrapper for tests
- `examples/static_html_automation.py` - driving static pages
- `examples/element_discovery.py` - the reconnaissance pattern in code
- `examples/console_logging.py` - capturing browser logs
- `SKILL.md`, `LICENSE.txt`

## Key takeaways for your own skills

- Put **decision trees at the top**: routing Claude to the right sub-workflow early prevents most tool misuse.
- Worked examples (three runnable scripts) teach faster than API documentation.

## See it on GitHub

[skills/webapp-testing](https://github.com/anthropics/skills/tree/main/skills/webapp-testing)

---

# Xlsx Skill - Build & Analyze Spreadsheets with Claude
URL: http://www.claudeskills.org/docs/skills-cases/xlsx
Description: The Xlsx skill covers spreadsheet creation, formulas, formatting, and data analysis in Claude - see exactly how the skill is written and triggered.
Source: Content adapted from anthropics/skills (MIT).

## All Excel files

### Professional Font
- Use a consistent, professional font (e.g., Arial, Times New Roman) for all deliverables unless otherwise instructed by the user

### Zero Formula Errors
- Every Excel model MUST be delivered with ZERO formula errors (#REF!, #DIV/0!, #VALUE!, #N/A, #NAME?)

### Preserve Existing Templates (when updating templates)
- Study and EXACTLY match existing format, style, and conventions when modifying files
- Never impose standardized formatting on files with established patterns
- Existing template conventions ALWAYS override these guidelines

## Financial models

### Color Coding Standards
Unless otherwise stated by the user or existing template

#### Industry-Standard Color Conventions
- **Blue text (RGB: 0,0,255)**: Hardcoded inputs, and numbers users will change for scenarios
- **Black text (RGB: 0,0,0)**: ALL formulas and calculations
- **Green text (RGB: 0,128,0)**: Links pulling from other worksheets within same workbook
- **Red text (RGB: 255,0,0)**: External links to other files
- **Yellow background (RGB: 255,255,0)**: Key assumptions needing attention or cells that need to be updated

### Number Formatting Standards

#### Required Format Rules
- **Years**: Format as text strings (e.g., "2024" not "2,024")
- **Currency**: Use $#,##0 format; ALWAYS specify units in headers ("Revenue ($mm)")
- **Zeros**: Use number formatting to make all zeros "-", including percentages (e.g., "$#,##0;($#,##0);-")
- **Percentages**: Default to 0.0% format (one decimal)
- **Multiples**: Format as 0.0x for valuation multiples (EV/EBITDA, P/E)
- **Negative numbers**: Use parentheses (123) not minus -123

### Formula Construction Rules

#### Assumptions Placement
- Place ALL assumptions (growth rates, margins, multiples, etc.) in separate assumption cells
- Use cell references instead of hardcoded values in formulas
- Example: Use =B5*(1+$B$6) instead of =B5*1.05

#### Formula Error Prevention
- Verify all cell references are correct
- Check for off-by-one errors in ranges
- Ensure consistent formulas across all projection periods
- Test with edge cases (zero values, negative numbers)
- Verify no unintended circular references

#### Documentation Requirements for Hardcodes
- Comment or in cells beside (if end of table). Format: "Source: [System/Document], [Date], [Specific Reference], [URL if applicable]"
- Examples:
- "Source: Company 10-K, FY2024, Page 45, Revenue Note, [SEC EDGAR URL]"
- "Source: Company 10-Q, Q2 2025, Exhibit 99.1, [SEC EDGAR URL]"
- "Source: Bloomberg Terminal, 8/15/2025, AAPL US Equity"
- "Source: FactSet, 8/20/2025, Consensus Estimates Screen"

# XLSX creation, editing, and analysis

## Overview

A user may ask you to create, edit, or analyze the contents of an .xlsx file. You have different tools and workflows available for different tasks.

## Important Requirements

**LibreOffice Required for Formula Recalculation**: You can assume LibreOffice is installed for recalculating formula values using the `scripts/recalc.py` script. The script automatically configures LibreOffice on first run, including in sandboxed environments where Unix sockets are restricted (handled by `scripts/office/soffice.py`)

## Reading and analyzing data

### Data analysis with pandas
For data analysis, visualization, and basic operations, use **pandas** which provides powerful data manipulation capabilities:

```python
import pandas as pd

# Read Excel
df = pd.read_excel('file.xlsx') # Default: first sheet
all_sheets = pd.read_excel('file.xlsx', sheet_name=None) # All sheets as dict

# Analyze
df.head() # Preview data
df.info() # Column info
df.describe() # Statistics

# Write Excel
df.to_excel('output.xlsx', index=False)
```

## Excel File Workflows

## CRITICAL: Use Formulas, Not Hardcoded Values

**Always use Excel formulas instead of calculating values in Python and hardcoding them.** This ensures the spreadsheet remains dynamic and updateable.

### WRONG - Hardcoding Calculated Values
```python
# Bad: Calculating in Python and hardcoding result
total = df['Sales'].sum()
sheet['B10'] = total # Hardcodes 5000

# Bad: Computing growth rate in Python
growth = (df.iloc[-1]['Revenue'] - df.iloc[0]['Revenue']) / df.iloc[0]['Revenue']
sheet['C5'] = growth # Hardcodes 0.15

# Bad: Python calculation for average
avg = sum(values) / len(values)
sheet['D20'] = avg # Hardcodes 42.5
```

### CORRECT - Using Excel Formulas
```python
# Good: Let Excel calculate the sum
sheet['B10'] = '=SUM(B2:B9)'

# Good: Growth rate as Excel formula
sheet['C5'] = '=(C4-C2)/C2'

# Good: Average using Excel function
sheet['D20'] = '=AVERAGE(D2:D19)'
```

This applies to ALL calculations - totals, percentages, ratios, differences, etc. The spreadsheet should be able to recalculate when source data changes.

## Common Workflow
1. **Choose tool**: pandas for data, openpyxl for formulas/formatting
2. **Create/Load**: Create new workbook or load existing file
3. **Modify**: Add/edit data, formulas, and formatting
4. **Save**: Write to file
5. **Recalculate formulas (MANDATORY IF USING FORMULAS)**: Use the scripts/recalc.py script
```bash
python scripts/recalc.py output.xlsx
```
6. **Verify and fix any errors**:
- The script returns JSON with error details
- If `status` is `errors_found`, check `error_summary` for specific error types and locations
- Fix the identified errors and recalculate again
- Common errors to fix:
- `#REF!`: Invalid cell references
- `#DIV/0!`: Division by zero
- `#VALUE!`: Wrong data type in formula
- `#NAME?`: Unrecognized formula name

### Creating new Excel files

```python
# Using openpyxl for formulas and formatting
from openpyxl import Workbook
from openpyxl.styles import Font, PatternFill, Alignment

wb = Workbook()
sheet = wb.active

# Add data
sheet['A1'] = 'Hello'
sheet['B1'] = 'World'
sheet.append(['Row', 'of', 'data'])

# Add formula
sheet['B2'] = '=SUM(A1:A10)'

# Formatting
sheet['A1'].font = Font(bold=True, color='FF0000')
sheet['A1'].fill = PatternFill('solid', start_color='FFFF00')
sheet['A1'].alignment = Alignment(horizontal='center')

# Column width
sheet.column_dimensions['A'].width = 20

wb.save('output.xlsx')
```

### Editing existing Excel files

```python
# Using openpyxl to preserve formulas and formatting
from openpyxl import load_workbook

# Load existing file
wb = load_workbook('existing.xlsx')
sheet = wb.active # or wb['SheetName'] for specific sheet

# Working with multiple sheets
for sheet_name in wb.sheetnames:
sheet = wb[sheet_name]
print(f"Sheet: {sheet_name}")

# Modify cells
sheet['A1'] = 'New Value'
sheet.insert_rows(2) # Insert row at position 2
sheet.delete_cols(3) # Delete column 3

# Add new sheet
new_sheet = wb.create_sheet('NewSheet')
new_sheet['A1'] = 'Data'

wb.save('modified.xlsx')
```

## Recalculating formulas

Excel files created or modified by openpyxl contain formulas as strings but not calculated values. Use the provided `scripts/recalc.py` script to recalculate formulas:

```bash
python scripts/recalc.py [timeout_seconds]
```

Example:
```bash
python scripts/recalc.py output.xlsx 30
```

The script:
- Automatically sets up LibreOffice macro on first run
- Recalculates all formulas in all sheets
- Scans ALL cells for Excel errors (#REF!, #DIV/0!, etc.)
- Returns JSON with detailed error locations and counts
- Works on both Linux and macOS

## Formula Verification Checklist

Quick checks to ensure formulas work correctly:

### Essential Verification
- [ ] **Test 2-3 sample references**: Verify they pull correct values before building full model
- [ ] **Column mapping**: Confirm Excel columns match (e.g., column 64 = BL, not BK)
- [ ] **Row offset**: Remember Excel rows are 1-indexed (DataFrame row 5 = Excel row 6)

### Common Pitfalls
- [ ] **NaN handling**: Check for null values with `pd.notna()`
- [ ] **Far-right columns**: FY data often in columns 50+
- [ ] **Multiple matches**: Search all occurrences, not just first
- [ ] **Division by zero**: Check denominators before using `/` in formulas (#DIV/0!)
- [ ] **Wrong references**: Verify all cell references point to intended cells (#REF!)
- [ ] **Cross-sheet references**: Use correct format (Sheet1!A1) for linking sheets

### Formula Testing Strategy
- [ ] **Start small**: Test formulas on 2-3 cells before applying broadly
- [ ] **Verify dependencies**: Check all cells referenced in formulas exist
- [ ] **Test edge cases**: Include zero, negative, and very large values

### Interpreting scripts/recalc.py Output
The script returns JSON with error details:
```json
{
"status": "success", // or "errors_found"
"total_errors": 0, // Total error count
"total_formulas": 42, // Number of formulas in file
"error_summary": { // Only present if errors found
"#REF!": {
"count": 2,
"locations": ["Sheet1!B5", "Sheet1!C10"]
}
}
}
```

## Best Practices

### Library Selection
- **pandas**: Best for data analysis, bulk operations, and simple data export
- **openpyxl**: Best for complex formatting, formulas, and Excel-specific features

### Working with openpyxl
- Cell indices are 1-based (row=1, column=1 refers to cell A1)
- Use `data_only=True` to read calculated values: `load_workbook('file.xlsx', data_only=True)`
- **Warning**: If opened with `data_only=True` and saved, formulas are replaced with values and permanently lost
- For large files: Use `read_only=True` for reading or `write_only=True` for writing
- Formulas are preserved but not evaluated - use scripts/recalc.py to update values

### Working with pandas
- Specify data types to avoid inference issues: `pd.read_excel('file.xlsx', dtype={'id': str})`
- For large files, read specific columns: `pd.read_excel('file.xlsx', usecols=['A', 'C', 'E'])`
- Handle dates properly: `pd.read_excel('file.xlsx', parse_dates=['date_column'])`

## Code Style Guidelines
**IMPORTANT**: When generating Python code for Excel operations:
- Write minimal, concise Python code without unnecessary comments
- Avoid verbose variable names and redundant operations
- Avoid unnecessary print statements

**For Excel files themselves**:
- Add comments to cells with complex formulas or important assumptions
- Document data sources for hardcoded values
- Include notes for key calculations and model sections

## Resource Files

### LICENSE.txt

[Download LICENSE.txt](/skills/xlsx/LICENSE.txt)

_Binary resource_

### scripts/office/helpers/__init__.py

[Download scripts/office/helpers/__init__.py](/skills/xlsx/scripts/office/helpers/__init__.py)

_Binary resource_

### scripts/office/helpers/merge_runs.py

[Download scripts/office/helpers/merge_runs.py](/skills/xlsx/scripts/office/helpers/merge_runs.py)

```python
"""Merge adjacent runs with identical formatting in DOCX.

Merges adjacent elements that have identical properties.
Works on runs in paragraphs and inside tracked changes (, ).

Also:
- Removes rsid attributes from runs (revision metadata that doesn't affect rendering)
- Removes proofErr elements (spell/grammar markers that block merging)
"""

from pathlib import Path

import defusedxml.minidom

def merge_runs(input_dir: str) -> tuple[int, str]:
doc_xml = Path(input_dir) / "word" / "document.xml"

if not doc_xml.exists():
return 0, f"Error: {doc_xml} not found"

try:
dom = defusedxml.minidom.parseString(doc_xml.read_text(encoding="utf-8"))
root = dom.documentElement

_remove_elements(root, "proofErr")
_strip_run_rsid_attrs(root)

containers = {run.parentNode for run in _find_elements(root, "r")}

merge_count = 0
for container in containers:
merge_count += _merge_runs_in(container)

doc_xml.write_bytes(dom.toxml(encoding="UTF-8"))
return merge_count, f"Merged {merge_count} runs"

except Exception as e:
return 0, f"Error: {e}"

def _find_elements(root, tag: str) -> list:
results = []

def traverse(node):
if node.nodeType == node.ELEMENT_NODE:
name = node.localName or node.tagName
if name == tag or name.endswith(f":{tag}"):
results.append(node)
for child in node.childNodes:
traverse(child)

traverse(root)
return results

def _get_child(parent, tag: str):
for child in parent.childNodes:
if child.nodeType == child.ELEMENT_NODE:
name = child.localName or child.tagName
if name == tag or name.endswith(f":{tag}"):
return child
return None

def _get_children(parent, tag: str) -> list:
results = []
for child in parent.childNodes:
if child.nodeType == child.ELEMENT_NODE:
name = child.localName or child.tagName
if name == tag or name.endswith(f":{tag}"):
results.append(child)
return results

def _is_adjacent(elem1, elem2) -> bool:
node = elem1.nextSibling
while node:
if node == elem2:
return True
if node.nodeType == node.ELEMENT_NODE:
return False
if node.nodeType == node.TEXT_NODE and node.data.strip():
return False
node = node.nextSibling
return False

def _remove_elements(root, tag: str):
for elem in _find_elements(root, tag):
if elem.parentNode:
elem.parentNode.removeChild(elem)

def _strip_run_rsid_attrs(root):
for run in _find_elements(root, "r"):
for attr in list(run.attributes.values()):
if "rsid" in attr.name.lower():
run.removeAttribute(attr.name)

def _merge_runs_in(container) -> int:
merge_count = 0
run = _first_child_run(container)

while run:
while True:
next_elem = _next_element_sibling(run)
if next_elem and _is_run(next_elem) and _can_merge(run, next_elem):
_merge_run_content(run, next_elem)
container.removeChild(next_elem)
merge_count += 1
else:
break

_consolidate_text(run)
run = _next_sibling_run(run)

return merge_count

def _first_child_run(container):
for child in container.childNodes:
if child.nodeType == child.ELEMENT_NODE and _is_run(child):
return child
return None

def _next_element_sibling(node):
sibling = node.nextSibling
while sibling:
if sibling.nodeType == sibling.ELEMENT_NODE:
return sibling
sibling = sibling.nextSibling
return None

def _next_sibling_run(node):
sibling = node.nextSibling
while sibling:
if sibling.nodeType == sibling.ELEMENT_NODE:
if _is_run(sibling):
return sibling
sibling = sibling.nextSibling
return None

def _is_run(node) -> bool:
name = node.localName or node.tagName
return name == "r" or name.endswith(":r")

def _can_merge(run1, run2) -> bool:
rpr1 = _get_child(run1, "rPr")
rpr2 = _get_child(run2, "rPr")

if (rpr1 is None) != (rpr2 is None):
return False
if rpr1 is None:
return True
return rpr1.toxml() == rpr2.toxml()

def _merge_run_content(target, source):
for child in list(source.childNodes):
if child.nodeType == child.ELEMENT_NODE:
name = child.localName or child.tagName
if name != "rPr" and not name.endswith(":rPr"):
target.appendChild(child)

def _consolidate_text(run):
t_elements = _get_children(run, "t")

for i in range(len(t_elements) - 1, 0, -1):
curr, prev = t_elements[i], t_elements[i - 1]

if _is_adjacent(prev, curr):
prev_text = prev.firstChild.data if prev.firstChild else ""
curr_text = curr.firstChild.data if curr.firstChild else ""
merged = prev_text + curr_text

if prev.firstChild:
prev.firstChild.data = merged
else:
prev.appendChild(run.ownerDocument.createTextNode(merged))

if merged.startswith(" ") or merged.endswith(" "):
prev.setAttribute("xml:space", "preserve")
elif prev.hasAttribute("xml:space"):
prev.removeAttribute("xml:space")

run.removeChild(curr)
```

### scripts/office/helpers/simplify_redlines.py

[Download scripts/office/helpers/simplify_redlines.py](/skills/xlsx/scripts/office/helpers/simplify_redlines.py)

```python
"""Simplify tracked changes by merging adjacent w:ins or w:del elements.

Merges adjacent elements from the same author into a single element.
Same for elements. This makes heavily-redlined documents easier to
work with by reducing the number of tracked change wrappers.

Rules:
- Only merges w:ins with w:ins, w:del with w:del (same element type)
- Only merges if same author (ignores timestamp differences)
- Only merges if truly adjacent (only whitespace between them)
"""

import xml.etree.ElementTree as ET
import zipfile
from pathlib import Path

import defusedxml.minidom

WORD_NS = "http://schemas.openxmlformats.org/wordprocessingml/2006/main"

def simplify_redlines(input_dir: str) -> tuple[int, str]:
doc_xml = Path(input_dir) / "word" / "document.xml"

if not doc_xml.exists():
return 0, f"Error: {doc_xml} not found"

try:
dom = defusedxml.minidom.parseString(doc_xml.read_text(encoding="utf-8"))
root = dom.documentElement

merge_count = 0

containers = _find_elements(root, "p") + _find_elements(root, "tc")

for container in containers:
merge_count += _merge_tracked_changes_in(container, "ins")
merge_count += _merge_tracked_changes_in(container, "del")

doc_xml.write_bytes(dom.toxml(encoding="UTF-8"))
return merge_count, f"Simplified {merge_count} tracked changes"

except Exception as e:
return 0, f"Error: {e}"

def _merge_tracked_changes_in(container, tag: str) -> int:
merge_count = 0

tracked = [
child
for child in container.childNodes
if child.nodeType == child.ELEMENT_NODE and _is_element(child, tag)
]

if len(tracked) < 2:
return 0

i = 0
while i < len(tracked) - 1:
curr = tracked[i]
next_elem = tracked[i + 1]

if _can_merge_tracked(curr, next_elem):
_merge_tracked_content(curr, next_elem)
container.removeChild(next_elem)
tracked.pop(i + 1)
merge_count += 1
else:
i += 1

return merge_count

def _is_element(node, tag: str) -> bool:
name = node.localName or node.tagName
return name == tag or name.endswith(f":{tag}")

def _get_author(elem) -> str:
author = elem.getAttribute("w:author")
if not author:
for attr in elem.attributes.values():
if attr.localName == "author" or attr.name.endswith(":author"):
return attr.value
return author

def _can_merge_tracked(elem1, elem2) -> bool:
if _get_author(elem1) != _get_author(elem2):
return False

node = elem1.nextSibling
while node and node != elem2:
if node.nodeType == node.ELEMENT_NODE:
return False
if node.nodeType == node.TEXT_NODE and node.data.strip():
return False
node = node.nextSibling

return True

def _merge_tracked_content(target, source):
while source.firstChild:
child = source.firstChild
source.removeChild(child)
target.appendChild(child)

def _find_elements(root, tag: str) -> list:
results = []

def traverse(node):
if node.nodeType == node.ELEMENT_NODE:
name = node.localName or node.tagName
if name == tag or name.endswith(f":{tag}"):
results.append(node)
for child in node.childNodes:
traverse(child)

traverse(root)
return results

def get_tracked_change_authors(doc_xml_path: Path) -> dict[str, int]:
if not doc_xml_path.exists():
return {}

try:
tree = ET.parse(doc_xml_path)
root = tree.getroot()
except ET.ParseError:
return {}

namespaces = {"w": WORD_NS}
author_attr = f"{{{WORD_NS}}}author"

authors: dict[str, int] = {}
for tag in ["ins", "del"]:
for elem in root.findall(f".//w:{tag}", namespaces):
author = elem.get(author_attr)
if author:
authors[author] = authors.get(author, 0) + 1

return authors

def _get_authors_from_docx(docx_path: Path) -> dict[str, int]:
try:
with zipfile.ZipFile(docx_path, "r") as zf:
if "word/document.xml" not in zf.namelist():
return {}
with zf.open("word/document.xml") as f:
tree = ET.parse(f)
root = tree.getroot()

namespaces = {"w": WORD_NS}
author_attr = f"{{{WORD_NS}}}author"

authors: dict[str, int] = {}
for tag in ["ins", "del"]:
for elem in root.findall(f".//w:{tag}", namespaces):
author = elem.get(author_attr)
if author:
authors[author] = authors.get(author, 0) + 1
return authors
except (zipfile.BadZipFile, ET.ParseError):
return {}

def infer_author(modified_dir: Path, original_docx: Path, default: str = "Claude") -> str:
modified_xml = modified_dir / "word" / "document.xml"
modified_authors = get_tracked_change_authors(modified_xml)

if not modified_authors:
return default

original_authors = _get_authors_from_docx(original_docx)

new_changes: dict[str, int] = {}
for author, count in modified_authors.items():
original_count = original_authors.get(author, 0)
diff = count - original_count
if diff > 0:
new_changes[author] = diff

if not new_changes:
return default

if len(new_changes) == 1:
return next(iter(new_changes))

raise ValueError(
f"Multiple authors added new changes: {new_changes}. "
"Cannot infer which author to validate."
)
```

### scripts/office/pack.py

[Download scripts/office/pack.py](/skills/xlsx/scripts/office/pack.py)

```python
"""Pack a directory into a DOCX, PPTX, or XLSX file.

Validates with auto-repair, condenses XML formatting, and creates the Office file.

Usage:
python pack.py [--original ] [--validate true|false]

Examples:
python pack.py unpacked/ output.docx --original input.docx
python pack.py unpacked/ output.pptx --validate false
"""

import argparse
import sys
import shutil
import tempfile
import zipfile
from pathlib import Path

import defusedxml.minidom

from validators import DOCXSchemaValidator, PPTXSchemaValidator, RedliningValidator

def pack(
input_directory: str,
output_file: str,
original_file: str | None = None,
validate: bool = True,
infer_author_func=None,
) -> tuple[None, str]:
input_dir = Path(input_directory)
output_path = Path(output_file)
suffix = output_path.suffix.lower()

if not input_dir.is_dir():
return None, f"Error: {input_dir} is not a directory"

if suffix not in {".docx", ".pptx", ".xlsx"}:
return None, f"Error: {output_file} must be a .docx, .pptx, or .xlsx file"

if validate and original_file:
original_path = Path(original_file)
if original_path.exists():
success, output = _run_validation(
input_dir, original_path, suffix, infer_author_func
)
if output:
print(output)
if not success:
return None, f"Error: Validation failed for {input_dir}"

with tempfile.TemporaryDirectory() as temp_dir:
temp_content_dir = Path(temp_dir) / "content"
shutil.copytree(input_dir, temp_content_dir)

for pattern in ["*.xml", "*.rels"]:
for xml_file in temp_content_dir.rglob(pattern):
_condense_xml(xml_file)

output_path.parent.mkdir(parents=True, exist_ok=True)
with zipfile.ZipFile(output_path, "w", zipfile.ZIP_DEFLATED) as zf:
for f in temp_content_dir.rglob("*"):
if f.is_file():
zf.write(f, f.relative_to(temp_content_dir))

return None, f"Successfully packed {input_dir} to {output_file}"

def _run_validation(
unpacked_dir: Path,
original_file: Path,
suffix: str,
infer_author_func=None,
) -> tuple[bool, str | None]:
output_lines = []
validators = []

if suffix == ".docx":
author = "Claude"
if infer_author_func:
try:
author = infer_author_func(unpacked_dir, original_file)
except ValueError as e:
print(f"Warning: {e} Using default author 'Claude'.", file=sys.stderr)

validators = [
DOCXSchemaValidator(unpacked_dir, original_file),
RedliningValidator(unpacked_dir, original_file, author=author),
]
elif suffix == ".pptx":
validators = [PPTXSchemaValidator(unpacked_dir, original_file)]

if not validators:
return True, None

total_repairs = sum(v.repair() for v in validators)
if total_repairs:
output_lines.append(f"Auto-repaired {total_repairs} issue(s)")

success = all(v.validate() for v in validators)

if success:
output_lines.append("All validations PASSED!")

return success, "\n".join(output_lines) if output_lines else None

def _condense_xml(xml_file: Path) -> None:
try:
with open(xml_file, encoding="utf-8") as f:
dom = defusedxml.minidom.parse(f)

for element in dom.getElementsByTagName("*"):
if element.tagName.endswith(":t"):
continue

for child in list(element.childNodes):
if (
child.nodeType == child.TEXT_NODE
and child.nodeValue
and child.nodeValue.strip() == ""
) or child.nodeType == child.COMMENT_NODE:
element.removeChild(child)

xml_file.write_bytes(dom.toxml(encoding="UTF-8"))
except Exception as e:
print(f"ERROR: Failed to parse {xml_file.name}: {e}", file=sys.stderr)
raise

if __name__ == "__main__":
parser = argparse.ArgumentParser(
description="Pack a directory into a DOCX, PPTX, or XLSX file"
)
parser.add_argument("input_directory", help="Unpacked Office document directory")
parser.add_argument("output_file", help="Output Office file (.docx/.pptx/.xlsx)")
parser.add_argument(
"--original",
help="Original file for validation comparison",
)
parser.add_argument(
"--validate",
type=lambda x: x.lower() == "true",
default=True,
metavar="true|false",
help="Run validation with auto-repair (default: true)",
)
args = parser.parse_args()

_, message = pack(
args.input_directory,
args.output_file,
original_file=args.original,
validate=args.validate,
)
print(message)

if "Error" in message:
sys.exit(1)
```

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-chart.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-chart.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-chart.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-chartDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-chartDrawing.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-chartDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-diagram.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-diagram.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-diagram.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-lockedCanvas.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-lockedCanvas.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-lockedCanvas.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-main.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-main.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-main.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-picture.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-picture.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-picture.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-spreadsheetDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-spreadsheetDrawing.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-spreadsheetDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/dml-wordprocessingDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/dml-wordprocessingDrawing.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/dml-wordprocessingDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/pml.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/pml.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/pml.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-additionalCharacteristics.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-additionalCharacteristics.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-additionalCharacteristics.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-bibliography.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-bibliography.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-bibliography.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-commonSimpleTypes.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-commonSimpleTypes.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-commonSimpleTypes.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-customXmlDataProperties.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-customXmlDataProperties.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-customXmlDataProperties.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-customXmlSchemaProperties.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-customXmlSchemaProperties.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-customXmlSchemaProperties.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesCustom.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesCustom.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesCustom.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesExtended.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesExtended.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesExtended.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesVariantTypes.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesVariantTypes.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-documentPropertiesVariantTypes.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-math.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-math.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-math.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/shared-relationshipReference.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/shared-relationshipReference.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/shared-relationshipReference.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/sml.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/sml.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/sml.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/vml-main.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/vml-main.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/vml-main.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/vml-officeDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/vml-officeDrawing.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/vml-officeDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/vml-presentationDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/vml-presentationDrawing.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/vml-presentationDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/vml-spreadsheetDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/vml-spreadsheetDrawing.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/vml-spreadsheetDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/vml-wordprocessingDrawing.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/vml-wordprocessingDrawing.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/vml-wordprocessingDrawing.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/wml.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/wml.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/wml.xsd)

_Binary resource_

### scripts/office/schemas/ISO-IEC29500-4_2016/xml.xsd

[Download scripts/office/schemas/ISO-IEC29500-4_2016/xml.xsd](/skills/xlsx/scripts/office/schemas/ISO-IEC29500-4_2016/xml.xsd)

_Binary resource_

### scripts/office/schemas/ecma/fouth-edition/opc-contentTypes.xsd

[Download scripts/office/schemas/ecma/fouth-edition/opc-contentTypes.xsd](/skills/xlsx/scripts/office/schemas/ecma/fouth-edition/opc-contentTypes.xsd)

_Binary resource_

### scripts/office/schemas/ecma/fouth-edition/opc-coreProperties.xsd

[Download scripts/office/schemas/ecma/fouth-edition/opc-coreProperties.xsd](/skills/xlsx/scripts/office/schemas/ecma/fouth-edition/opc-coreProperties.xsd)

_Binary resource_

### scripts/office/schemas/ecma/fouth-edition/opc-digSig.xsd

[Download scripts/office/schemas/ecma/fouth-edition/opc-digSig.xsd](/skills/xlsx/scripts/office/schemas/ecma/fouth-edition/opc-digSig.xsd)

_Binary resource_

### scripts/office/schemas/ecma/fouth-edition/opc-relationships.xsd

[Download scripts/office/schemas/ecma/fouth-edition/opc-relationships.xsd](/skills/xlsx/scripts/office/schemas/ecma/fouth-edition/opc-relationships.xsd)

_Binary resource_

### scripts/office/schemas/mce/mc.xsd

[Download scripts/office/schemas/mce/mc.xsd](/skills/xlsx/scripts/office/schemas/mce/mc.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-2010.xsd

[Download scripts/office/schemas/microsoft/wml-2010.xsd](/skills/xlsx/scripts/office/schemas/microsoft/wml-2010.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-2012.xsd

[Download scripts/office/schemas/microsoft/wml-2012.xsd](/skills/xlsx/scripts/office/schemas/microsoft/wml-2012.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-2018.xsd

[Download scripts/office/schemas/microsoft/wml-2018.xsd](/skills/xlsx/scripts/office/schemas/microsoft/wml-2018.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-cex-2018.xsd

[Download scripts/office/schemas/microsoft/wml-cex-2018.xsd](/skills/xlsx/scripts/office/schemas/microsoft/wml-cex-2018.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-cid-2016.xsd

[Download scripts/office/schemas/microsoft/wml-cid-2016.xsd](/skills/xlsx/scripts/office/schemas/microsoft/wml-cid-2016.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-sdtdatahash-2020.xsd

[Download scripts/office/schemas/microsoft/wml-sdtdatahash-2020.xsd](/skills/xlsx/scripts/office/schemas/microsoft/wml-sdtdatahash-2020.xsd)

_Binary resource_

### scripts/office/schemas/microsoft/wml-symex-2015.xsd

[Download scripts/office/schemas/microsoft/wml-symex-2015.xsd](/skills/xlsx/scripts/office/schemas/microsoft/wml-symex-2015.xsd)

_Binary resource_

### scripts/office/soffice.py

[Download scripts/office/soffice.py](/skills/xlsx/scripts/office/soffice.py)

```python
"""
Helper for running LibreOffice (soffice) in environments where AF_UNIX
sockets may be blocked (e.g., sandboxed VMs). Detects the restriction
at runtime and applies an LD_PRELOAD shim if needed.

Usage:
from office.soffice import run_soffice, get_soffice_env

# Option 1 – run soffice directly
result = run_soffice(["--headless", "--convert-to", "pdf", "input.docx"])

# Option 2 – get env dict for your own subprocess calls
env = get_soffice_env()
subprocess.run(["soffice", ...], env=env)
"""

import os
import socket
import subprocess
import tempfile
from pathlib import Path

def get_soffice_env() -> dict:
env = os.environ.copy()
env["SAL_USE_VCLPLUGIN"] = "svp"

if _needs_shim():
shim = _ensure_shim()
env["LD_PRELOAD"] = str(shim)

return env

def run_soffice(args: list[str], **kwargs) -> subprocess.CompletedProcess:
env = get_soffice_env()
return subprocess.run(["soffice"] + args, env=env, **kwargs)

_SHIM_SO = Path(tempfile.gettempdir()) / "lo_socket_shim.so"

def _needs_shim() -> bool:
try:
s = socket.socket(socket.AF_UNIX, socket.SOCK_STREAM)
s.close()
return False
except OSError:
return True

def _ensure_shim() -> Path:
if _SHIM_SO.exists():
return _SHIM_SO

src = Path(tempfile.gettempdir()) / "lo_socket_shim.c"
src.write_text(_SHIM_SOURCE)
subprocess.run(
["gcc", "-shared", "-fPIC", "-o", str(_SHIM_SO), str(src), "-ldl"],
check=True,
capture_output=True,
)
src.unlink()
return _SHIM_SO

_SHIM_SOURCE = r"""
#define _GNU_SOURCE
#include
#include
#include
#include
#include
#include
#include

static int (*real_socket)(int, int, int);
static int (*real_socketpair)(int, int, int, int[2]);
static int (*real_listen)(int, int);
static int (*real_accept)(int, struct sockaddr *, socklen_t *);
static int (*real_close)(int);
static int (*real_read)(int, void *, size_t);

/* Per-FD bookkeeping (FDs >= 1024 are passed through unshimmed). */
static int is_shimmed[1024];
static int peer_of[1024];
static int wake_r[1024]; /* accept() blocks reading this */
static int wake_w[1024]; /* close() writes to this */
static int listener_fd = -1; /* FD that received listen() */

__attribute__((constructor))
static void init(void) {
real_socket = dlsym(RTLD_NEXT, "socket");
real_socketpair = dlsym(RTLD_NEXT, "socketpair");
real_listen = dlsym(RTLD_NEXT, "listen");
real_accept = dlsym(RTLD_NEXT, "accept");
real_close = dlsym(RTLD_NEXT, "close");
real_read = dlsym(RTLD_NEXT, "read");
for (int i = 0; i < 1024; i++) {
peer_of[i] = -1;
wake_r[i] = -1;
wake_w[i] = -1;
}
}

/* ---- socket ---------------------------------------------------------- */
int socket(int domain, int type, int protocol) {
if (domain == AF_UNIX) {
int fd = real_socket(domain, type, protocol);
if (fd >= 0) return fd;
/* socket(AF_UNIX) blocked – fall back to socketpair(). */
int sv[2];
if (real_socketpair(domain, type, protocol, sv) == 0) {
if (sv[0] >= 0 && sv[0] < 1024) {
is_shimmed[sv[0]] = 1;
peer_of[sv[0]] = sv[1];
int wp[2];
if (pipe(wp) == 0) {
wake_r[sv[0]] = wp[0];
wake_w[sv[0]] = wp[1];
}
}
return sv[0];
}
errno = EPERM;
return -1;
}
return real_socket(domain, type, protocol);
}

/* ---- listen ---------------------------------------------------------- */
int listen(int sockfd, int backlog) {
if (sockfd >= 0 && sockfd < 1024 && is_shimmed[sockfd]) {
listener_fd = sockfd;
return 0;
}
return real_listen(sockfd, backlog);
}

/* ---- accept ---------------------------------------------------------- */
int accept(int sockfd, struct sockaddr *addr, socklen_t *addrlen) {
if (sockfd >= 0 && sockfd < 1024 && is_shimmed[sockfd]) {
/* Block until close() writes to the wake pipe. */
if (wake_r[sockfd] >= 0) {
char buf;
real_read(wake_r[sockfd], &buf, 1);
}
errno = ECONNABORTED;
return -1;
}
return real_accept(sockfd, addr, addrlen);
}

/* ---- close ----------------------------------------------------------- */
int close(int fd) {
if (fd >= 0 && fd < 1024 && is_shimmed[fd]) {
int was_listener = (fd == listener_fd);
is_shimmed[fd] = 0;

if (wake_w[fd] >= 0) { /* unblock accept() */
char c = 0;
write(wake_w[fd], &c, 1);
real_close(wake_w[fd]);
wake_w[fd] = -1;
}
if (wake_r[fd] >= 0) { real_close(wake_r[fd]); wake_r[fd] = -1; }
if (peer_of[fd] >= 0) { real_close(peer_of[fd]); peer_of[fd] = -1; }

if (was_listener)
_exit(0); /* conversion done – exit */
}
return real_close(fd);
}
"""

if __name__ == "__main__":
import sys
result = run_soffice(sys.argv[1:])
sys.exit(result.returncode)
```

### scripts/office/unpack.py

[Download scripts/office/unpack.py](/skills/xlsx/scripts/office/unpack.py)

```python
"""Unpack Office files (DOCX, PPTX, XLSX) for editing.

Extracts the ZIP archive, pretty-prints XML files, and optionally:
- Merges adjacent runs with identical formatting (DOCX only)
- Simplifies adjacent tracked changes from same author (DOCX only)

Usage:
python unpack.py [options]

Examples:
python unpack.py document.docx unpacked/
python unpack.py presentation.pptx unpacked/
python unpack.py document.docx unpacked/ --merge-runs false
"""

import argparse
import sys
import zipfile
from pathlib import Path

import defusedxml.minidom

from helpers.merge_runs import merge_runs as do_merge_runs
from helpers.simplify_redlines import simplify_redlines as do_simplify_redlines

SMART_QUOTE_REPLACEMENTS = {
"\u201c": "“",
"\u201d": "”",
"\u2018": "‘",
"\u2019": "’",
}

def unpack(
input_file: str,
output_directory: str,
merge_runs: bool = True,
simplify_redlines: bool = True,
) -> tuple[None, str]:
input_path = Path(input_file)
output_path = Path(output_directory)
suffix = input_path.suffix.lower()

if not input_path.exists():
return None, f"Error: {input_file} does not exist"

if suffix not in {".docx", ".pptx", ".xlsx"}:
return None, f"Error: {input_file} must be a .docx, .pptx, or .xlsx file"

try:
output_path.mkdir(parents=True, exist_ok=True)

with zipfile.ZipFile(input_path, "r") as zf:
zf.extractall(output_path)

xml_files = list(output_path.rglob("*.xml")) + list(output_path.rglob("*.rels"))
for xml_file in xml_files:
_pretty_print_xml(xml_file)

message = f"Unpacked {input_file} ({len(xml_files)} XML files)"

if suffix == ".docx":
if simplify_redlines:
simplify_count, _ = do_simplify_redlines(str(output_path))
message += f", simplified {simplify_count} tracked changes"

if merge_runs:
merge_count, _ = do_merge_runs(str(output_path))
message += f", merged {merge_count} runs"

for xml_file in xml_files:
_escape_smart_quotes(xml_file)

return None, message

except zipfile.BadZipFile:
return None, f"Error: {input_file} is not a valid Office file"
except Exception as e:
return None, f"Error unpacking: {e}"

def _pretty_print_xml(xml_file: Path) -> None:
try:
content = xml_file.read_text(encoding="utf-8")
dom = defusedxml.minidom.parseString(content)
xml_file.write_bytes(dom.toprettyxml(indent=" ", encoding="utf-8"))
except Exception:
pass

def _escape_smart_quotes(xml_file: Path) -> None:
try:
content = xml_file.read_text(encoding="utf-8")
for char, entity in SMART_QUOTE_REPLACEMENTS.items():
content = content.replace(char, entity)
xml_file.write_text(content, encoding="utf-8")
except Exception:
pass

if __name__ == "__main__":
parser = argparse.ArgumentParser(
description="Unpack an Office file (DOCX, PPTX, XLSX) for editing"
)
parser.add_argument("input_file", help="Office file to unpack")
parser.add_argument("output_directory", help="Output directory")
parser.add_argument(
"--merge-runs",
type=lambda x: x.lower() == "true",
default=True,
metavar="true|false",
help="Merge adjacent runs with identical formatting (DOCX only, default: true)",
)
parser.add_argument(
"--simplify-redlines",
type=lambda x: x.lower() == "true",
default=True,
metavar="true|false",
help="Merge adjacent tracked changes from same author (DOCX only, default: true)",
)
args = parser.parse_args()

_, message = unpack(
args.input_file,
args.output_directory,
merge_runs=args.merge_runs,
simplify_redlines=args.simplify_redlines,
)
print(message)

if "Error" in message:
sys.exit(1)
```

### scripts/office/validate.py

[Download scripts/office/validate.py](/skills/xlsx/scripts/office/validate.py)

```python
"""
Command line tool to validate Office document XML files against XSD schemas and tracked changes.

Usage:
python validate.py [--original ] [--auto-repair] [--author NAME]

The first argument can be either:
- An unpacked directory containing the Office document XML files
- A packed Office file (.docx/.pptx/.xlsx) which will be unpacked to a temp directory

Auto-repair fixes:
- paraId/durableId values that exceed OOXML limits
- Missing xml:space="preserve" on w:t elements with whitespace
"""

import argparse
import sys
import tempfile
import zipfile
from pathlib import Path

from validators import DOCXSchemaValidator, PPTXSchemaValidator, RedliningValidator

def main():
parser = argparse.ArgumentParser(description="Validate Office document XML files")
parser.add_argument(
"path",
help="Path to unpacked directory or packed Office file (.docx/.pptx/.xlsx)",
)
parser.add_argument(
"--original",
required=False,
default=None,
help="Path to original file (.docx/.pptx/.xlsx). If omitted, all XSD errors are reported and redlining validation is skipped.",
)
parser.add_argument(
"-v",
"--verbose",
action="store_true",
help="Enable verbose output",
)
parser.add_argument(
"--auto-repair",
action="store_true",
help="Automatically repair common issues (hex IDs, whitespace preservation)",
)
parser.add_argument(
"--author",
default="Claude",
help="Author name for redlining validation (default: Claude)",
)
args = parser.parse_args()

path = Path(args.path)
assert path.exists(), f"Error: {path} does not exist"

original_file = None
if args.original:
original_file = Path(args.original)
assert original_file.is_file(), f"Error: {original_file} is not a file"
assert original_file.suffix.lower() in [".docx", ".pptx", ".xlsx"], (
f"Error: {original_file} must be a .docx, .pptx, or .xlsx file"
)

file_extension = (original_file or path).suffix.lower()
assert file_extension in [".docx", ".pptx", ".xlsx"], (
f"Error: Cannot determine file type from {path}. Use --original or provide a .docx/.pptx/.xlsx file."
)

if path.is_file() and path.suffix.lower() in [".docx", ".pptx", ".xlsx"]:
temp_dir = tempfile.mkdtemp()
with zipfile.ZipFile(path, "r") as zf:
zf.extractall(temp_dir)
unpacked_dir = Path(temp_dir)
else:
assert path.is_dir(), f"Error: {path} is not a directory or Office file"
unpacked_dir = path

match file_extension:
case ".docx":
validators = [
DOCXSchemaValidator(unpacked_dir, original_file, verbose=args.verbose),
]
if original_file:
validators.append(
RedliningValidator(unpacked_dir, original_file, verbose=args.verbose, author=args.author)
)
case ".pptx":
validators = [
PPTXSchemaValidator(unpacked_dir, original_file, verbose=args.verbose),
]
case _:
print(f"Error: Validation not supported for file type {file_extension}")
sys.exit(1)

if args.auto_repair:
total_repairs = sum(v.repair() for v in validators)
if total_repairs:
print(f"Auto-repaired {total_repairs} issue(s)")

success = all(v.validate() for v in validators)

if success:
print("All validations PASSED!")

sys.exit(0 if success else 1)

if __name__ == "__main__":
main()
```

### scripts/office/validators/__init__.py

[Download scripts/office/validators/__init__.py](/skills/xlsx/scripts/office/validators/__init__.py)

```python
"""
Validation modules for Word document processing.
"""

from .base import BaseSchemaValidator
from .docx import DOCXSchemaValidator
from .pptx import PPTXSchemaValidator
from .redlining import RedliningValidator

__all__ = [
"BaseSchemaValidator",
"DOCXSchemaValidator",
"PPTXSchemaValidator",
"RedliningValidator",
]
```

### scripts/office/validators/base.py

[Download scripts/office/validators/base.py](/skills/xlsx/scripts/office/validators/base.py)

_Binary resource_

### scripts/office/validators/docx.py

[Download scripts/office/validators/docx.py](/skills/xlsx/scripts/office/validators/docx.py)

_Binary resource_

### scripts/office/validators/pptx.py

[Download scripts/office/validators/pptx.py](/skills/xlsx/scripts/office/validators/pptx.py)

_Binary resource_

### scripts/office/validators/redlining.py

[Download scripts/office/validators/redlining.py](/skills/xlsx/scripts/office/validators/redlining.py)

_Binary resource_

### scripts/recalc.py

[Download scripts/recalc.py](/skills/xlsx/scripts/recalc.py)

```python
"""
Excel Formula Recalculation Script
Recalculates all formulas in an Excel file using LibreOffice
"""

import json
import os
import platform
import subprocess
import sys
from pathlib import Path

from office.soffice import get_soffice_env

from openpyxl import load_workbook

MACRO_DIR_MACOS = "~/Library/Application Support/LibreOffice/4/user/basic/Standard"
MACRO_DIR_LINUX = "~/.config/libreoffice/4/user/basic/Standard"
MACRO_FILENAME = "Module1.xba"

RECALCULATE_MACRO = """

Sub RecalculateAndSave()
ThisComponent.calculateAll()
ThisComponent.store()
ThisComponent.close(True)
End Sub
"""

def has_gtimeout():
try:
subprocess.run(
["gtimeout", "--version"], capture_output=True, timeout=1, check=False
)
return True
except (FileNotFoundError, subprocess.TimeoutExpired):
return False

def setup_libreoffice_macro():
macro_dir = os.path.expanduser(
MACRO_DIR_MACOS if platform.system() == "Darwin" else MACRO_DIR_LINUX
)
macro_file = os.path.join(macro_dir, MACRO_FILENAME)

if (
os.path.exists(macro_file)
and "RecalculateAndSave" in Path(macro_file).read_text()
):
return True

if not os.path.exists(macro_dir):
subprocess.run(
["soffice", "--headless", "--terminate_after_init"],
capture_output=True,
timeout=10,
env=get_soffice_env(),
)
os.makedirs(macro_dir, exist_ok=True)

try:
Path(macro_file).write_text(RECALCULATE_MACRO)
return True
except Exception:
return False

def recalc(filename, timeout=30):
if not Path(filename).exists():
return {"error": f"File {filename} does not exist"}

abs_path = str(Path(filename).absolute())

if not setup_libreoffice_macro():
return {"error": "Failed to setup LibreOffice macro"}

cmd = [
"soffice",
"--headless",
"--norestore",
"vnd.sun.star.script:Standard.Module1.RecalculateAndSave?language=Basic&location=application",
abs_path,
]

if platform.system() == "Linux":
cmd = ["timeout", str(timeout)] + cmd
elif platform.system() == "Darwin" and has_gtimeout():
cmd = ["gtimeout", str(timeout)] + cmd

result = subprocess.run(cmd, capture_output=True, text=True, env=get_soffice_env())

if result.returncode != 0 and result.returncode != 124:
error_msg = result.stderr or "Unknown error during recalculation"
if "Module1" in error_msg or "RecalculateAndSave" not in error_msg:
return {"error": "LibreOffice macro not configured properly"}
return {"error": error_msg}

try:
wb = load_workbook(filename, data_only=True)

excel_errors = [
"#VALUE!",
"#DIV/0!",
"#REF!",
"#NAME?",
"#NULL!",
"#NUM!",
"#N/A",
]
error_details = {err: [] for err in excel_errors}
total_errors = 0

for sheet_name in wb.sheetnames:
ws = wb[sheet_name]
for row in ws.iter_rows():
for cell in row:
if cell.value is not None and isinstance(cell.value, str):
for err in excel_errors:
if err in cell.value:
location = f"{sheet_name}!{cell.coordinate}"
error_details[err].append(location)
total_errors += 1
break

wb.close()

result = {
"status": "success" if total_errors == 0 else "errors_found",
"total_errors": total_errors,
"error_summary": {},
}

for err_type, locations in error_details.items():
if locations:
result["error_summary"][err_type] = {
"count": len(locations),
"locations": locations[:20],
}

wb_formulas = load_workbook(filename, data_only=False)
formula_count = 0
for sheet_name in wb_formulas.sheetnames:
ws = wb_formulas[sheet_name]
for row in ws.iter_rows():
for cell in row:
if (
cell.value
and isinstance(cell.value, str)
and cell.value.startswith("=")
):
formula_count += 1
wb_formulas.close()

result["total_formulas"] = formula_count

return result

except Exception as e:
return {"error": str(e)}

def main():
if len(sys.argv) < 2:
print("Usage: python recalc.py [timeout_seconds]")
print("\nRecalculates all formulas in an Excel file using LibreOffice")
print("\nReturns JSON with error details:")
print(" - status: 'success' or 'errors_found'")
print(" - total_errors: Total number of Excel errors found")
print(" - total_formulas: Number of formulas in the file")
print(" - error_summary: Breakdown by error type with locations")
print(" - #VALUE!, #DIV/0!, #REF!, #NAME?, #NULL!, #NUM!, #N/A")
sys.exit(1)

filename = sys.argv[1]
timeout = int(sys.argv[2]) if len(sys.argv) > 2 else 30

result = recalc(filename, timeout)
print(json.dumps(result, indent=2))

if __name__ == "__main__":
main()
```

## See in GitHub

[See in GitHub](https://github.com/anthropics/skills/tree/main/xlsx)

---

# Static Export
URL: http://www.claudeskills.org/docs/static-export
Description: Enable static export with Fumadocs
## Overview

Fumadocs is fully compatible with Next.js static export, allowing you to export the app as a static HTML site without a Node.js server.

```js title="next.config.mjs"
/**
* @type {import('next').NextConfig}
*/
const nextConfig = {
output: 'export',
};
```

## Search

### Cloud Solutions

Since the search functionality is powered by remote servers, static export works without configuration.

### Built-in Search

The default search config of Orama Search uses route handlers, which is not supported by static export.

Instead, you can build the search indexes statically following the [Orama Search](/docs/headless/search/orama#static-export) guide.
And enable static mode on search client from Root Provider:

```tsx title="app/layout.tsx"
import { RootProvider } from 'fumadocs-ui/provider';
import type { ReactNode } from 'react';

export default function RootLayout({ children }: { children: ReactNode }) {
return (

{children}

);
}
```

This allows the route handler to be statically cached into a single file, and search will be computed on browser instead.

---

# Themes
URL: http://www.claudeskills.org/docs/theme
Description: Add Theme to Fumadocs UI
## Usage

Note only Tailwind CSS v4 is supported:

```css title="Tailwind CSS"
@import 'tailwindcss';
@import 'fumadocs-ui/css/neutral.css';
@import 'fumadocs-ui/css/preset.css';

/* path of `fumadocs-ui` relative to the CSS file */
@source '../node_modules/fumadocs-ui/dist/**/*.js';
```

### Preflight Changes

By using the Tailwind CSS plugin, or the pre-built stylesheet, your default border, text and background
colors will be changed.

### Light/Dark Modes

Fumadocs supports light/dark modes with [`next-themes`](https://github.com/pacocoursey/next-themes), it is included in Root Provider.

See [Root Provider](/docs/layouts/root-provider#theme-provider) to learn more.

### RTL Layout

RTL (Right-to-left) layout is supported.

To enable RTL, set the `dir` prop to `rtl` in body and root provider (required for Radix UI).

```tsx
import { RootProvider } from 'fumadocs-ui/provider';
import type { ReactNode } from 'react';

export default function RootLayout({ children }: { children: ReactNode }) {
return (

{children}

);
}
```

### Prefix

Fumadocs UI has its own colors, animations, and utilities.
By default, it adds a `fd-` prefix to avoid conflicts with Shadcn UI or your own CSS variables.

You can use them without the prefix by adding some aliases:

```css title="Tailwind CSS"
@theme {
--color-primary: var(--color-fd-primary);
}
```

> You can use it with CSS media queries for responsive design.

### Layout Width

Customise the max width of docs layout with CSS Variables.

```css
:root {
--fd-layout-width: 1400px;
}
```

{/* */}

## Tailwind CSS Preset

The Tailwind CSS preset introduces new colors and extra utilities including `fd-steps`.

### Themes

It comes with many themes out-of-the-box, you can pick one you prefer.

```css
@import 'fumadocs-ui/css/.css';

/* Example */
@import 'fumadocs-ui/css/black.css';
```

![Neutral](/images/docs/themes/neutral.png)

![Black](/images/docs/themes/black.png)

![Vitepress](/images/docs/themes/vitepress.png)

![Dusk](/images/docs/themes/dusk.png)

![Catppuccin](/images/docs/themes/catppuccin.png)

![Ocean](/images/docs/themes/ocean.png)

![Purple](/images/docs/themes/purple.png)

### Colors

The design system was inspired by [Shadcn UI](https://ui.shadcn.com), you can easily customize the colors using CSS variables.

```css title="global.css"
:root {
--color-fd-background: hsl(0, 0%, 100%);
}

.dark {
--color-fd-background: hsl(0, 0%, 0%);
}
```

### Typography

We have a built-in plugin forked from [Tailwind CSS Typography](https://tailwindcss.com/docs/typography-plugin).

The plugin adds a `prose` class and variants to customise it.

```tsx

Good Heading

```

> The plugin works with and only with Fumadocs UI's MDX components, it may conflict with `@tailwindcss/typography`.
> If you need to use `@tailwindcss/typography` over the default plugin, [set a class name option](https://github.com/tailwindlabs/tailwindcss-typography/blob/main/README.md#changing-the-default-class-name) to avoid conflicts.

---

# What is Fumadocs
URL: http://www.claudeskills.org/docs/what-is-fumadocs
Description: Introducing Fumadocs, a docs framework that you can break.
Fumadocs was created because I wanted a more customisable experience for building docs, to be a docs framework that is not opinionated, **a "framework" that you can break**.

## Philosophy

**Less Abstraction:** Fumadocs expects you to write code and cooperate with the rest of your software.
While most frameworks are configured with a configuration file, they usually lack flexibility when you hope to tune its details.
You can’t control how they render the page nor the internal logic. Fumadocs shows you how the app works, instead of a single configuration file.

**Next.js Fundamentals:** It gives you the utilities and a good-looking UI.
You are still using features of Next.js App Router, like **Static Site Generation**. There is nothing new for Next.js developers, so you can use it with confidence.

**Opinionated on UI:** The only thing Fumadocs UI (the default theme) offers is **User Interface**. The UI is opinionated for bringing better mobile responsiveness and user experience.
Instead, we use a much more flexible approach inspired by Shadcn UI — [Fumadocs CLI](/docs/cli), so we can iterate our design quick, and welcome for more feedback about the UI.

## Why Fumadocs

Fumadocs is designed with flexibility in mind.

You can use `fumadocs-core` as a headless UI library and bring your own styles.
Fumadocs MDX is also a useful library to handle MDX content in Next.js. It also includes:

- Many built-in components.
- Typescript Twoslash, OpenAPI, and Math (KaTeX) integrations.
- Fast and optimized by default, natively built on App Router.
- Tight integration with Next.js, you can add it to an existing Next.js project easily.

You can read [Comparisons](/docs/comparisons) if you're interested.

### Documentation

Fumadocs focuses on **authoring experience**, it provides a beautiful theme and many docs automation tools.

It helps you to iterate your codebase faster while never leaving your docs behind.
You can take this site as an example of docs site built with Fumadocs.

### Blog sites

Since Next.js is already a powerful framework, most features can be implemented with **just Next.js**.

Fumadocs provides additional tooling for Next.js, including syntax highlighting, document search, and a default theme (Fumadocs UI).
It helps you to avoid reinventing the wheels.

## When to use Fumadocs

For most of the web applications, vanilla React.js is no longer enough.
Nowadays, we also wish to have a blog, a showcase page, a FAQ page, etc. With a
fancy UI that's breathtaking, in these cases, Fumadocs can help you build the
docs easier, with less boilerplate.

Fumadocs is maintained by Fuma and many contributors, with care on the maintainability of codebase.
While we don't aim to offer every functionality people wanted, we're more focused on making basic features perfect and well-maintained.
You can also help Fumadocs to be more useful by contributing!}
